3. PARTS LIST

(R)
LOCATION PARTS NO.
DESCRIPTION
CABINET & CHASSIS PARTS
5002
613 222 5113
CABINET MAIN-L5DD2
5003
613 220 8611
LEVER LOCK-L5DD2
5004
613 220 8642
SPRING LEVER-L5DD2
5005
613 211 0556
SPACER SHEET
5006
613 212 5079
SPACER-L5BU2/XE
5008
613 211 3656
MOUNTING SAFETY WIRE
5009
613 211 3649
COVER SAFETY WIRE
5017
636 097 2193
LABEL BLUE-L5BH2/US
5019
645 041 0314
FIXER,14.2X19.6
5028
613 220 8550
COVER PAN LEFT-L5DD2
5030
613 220 8567
COVER PAN RIGHT-L5DD2
5039
613 212 2672
DAMPER,FAN MOTOR
5050
613 222 0439
SPACER CABINET MAIN-L5DD2
5052
613 222 3522
HOLDER BOTTOM-L5DD
5054
613 222 5373
SHIELD TAPE-L5DD2
TB1
613 219 9162
COMPL PWB,TB-1
M2001
645 091 5192
MOTOR,FAN DC 0.55W
NJ500
411 212 7006
SCR BIN+SW 4X8
NJ510
411 191 9107
SCR BIN 3X8
NJ520
411 214 8902
SCR PAN+W 2X4
NJ540
411 030 7004
SCR BIN 2X6
NJ550
411 087 7705
WASHER V 3X8X0.5
NJ560
613 201 0016
PIPE
NJ570
411 030 7004
SCR BIN 2X6
NJ580
411 030 5406
SCR BIN 2X4
NJ587
411 030 7004
SCR BIN 2X6
NJ595
411 031 8604
SCR BIN 3X6
#1 refer to page 18.
