Camera unit (megapixel camera)
Hide thumbs

Advertisement

Table of Contents
LOCATION PARTS NO.
DESCRIPTION
R9508
301 226 1506
MT-GLAZE 0.000 ZA 1/16W
R9510
301 269 3901
MT-GLAZE 4.7K DC 1/16W
R9511
301 269 3901
MT-GLAZE 4.7K DC 1/16W
R9512
301 226 1506
MT-GLAZE 0.000 ZA 1/16W
R9513
301 226 1506
MT-GLAZE 0.000 ZA 1/16W
R9514
301 226 1506
MT-GLAZE 0.000 ZA 1/16W
R9515
301 258 9303
MT-GLAZE 220K DC 1/16W
R9516
301 258 9303
MT-GLAZE 220K DC 1/16W
R9517
301 262 2307
MT-GLAZE 1.0K DC 1/16W
R9519
301 226 1506
MT-GLAZE 0.000 ZA 1/16W
R9520
301 226 1506
MT-GLAZE 0.000 ZA 1/16W
R9523
301 226 1506
MT-GLAZE 0.000 ZA 1/16W
R9526
301 278 1806
MT-GLAZE
R9529
301 226 1506
MT-GLAZE 0.000 ZA 1/16W
R9801
301 105 7902
MT-GLAZE 0.000 ZA 1/16W
R9802
301 105 7902
MT-GLAZE 0.000 ZA 1/16W
R9807
301 105 7902
MT-GLAZE 0.000 ZA 1/16W
R9808
301 105 7902
MT-GLAZE 0.000 ZA 1/16W
R9809
301 105 7902
MT-GLAZE 0.000 ZA 1/16W
R9810
301 105 7902
MT-GLAZE 0.000 ZA 1/16W
R9811
301 105 7902
MT-GLAZE 0.000 ZA 1/16W
R9812
301 105 7902
MT-GLAZE 0.000 ZA 1/16W
(THERMISTOR)
TH301
308 054 7700
TH NCP15WF104F03-RC
(CONNECTORS)
CN101
645 076 4172
PLUG,PWB-PWB 30P (N.S.P)
CN102
645 072 3674
SOCKET,USB 5P (N.S.P)
CN103
645 076 4172
PLUG,PWB-PWB 30P (N.S.P)
CN104
645 079 6302
PLUG,PWB-PWB 50P (N.S.P)
CN105
645 078 7621
SOCKET,FPC 5P (N.S.P)
CN302
645 075 5033
PLUG,6P
CN951
645 095 2081
SOCKET,FPC 29P (N.S.P)
CN952
645 085 6150
SOCKET,FPC 6P (N.S.P)
COMPL PWB,CA-3
613 219 9117
(VARISTORS)
VA701
308 050 1504
VARISTOR AVR-M1608C220KT
VA702
308 050 1504
VARISTOR AVR-M1608C220KT
(SEMICONDUCTORS)
Q7001
305 131 4508
TR 2SD1767Q
Q7002
305 168 4502
TR 2SA2029-R
OR
305 168 4601
TR 2SA2029-S
Q8301
305 184 6009
TR UP03396
(INTEGRATED CIRCUITS)
IC701
410 691 8009
IC DS92LV16TVHG/NOPB
IC710
309 674 3509
IC THS7303PW
IC801
409 699 2607
IC LM3100MHX
IC811
409 699 2607
IC LM3100MHX
IC831
409 686 6205
IC SC4624MLT
IC832
409 677 2803
IC NJM2877F3-03
IC851
409 689 2709
IC XC9235A18CE
IC852
409 689 2709
IC XC9235A18CE
IC853
409 689 2709
IC XC9235A18CE
(DIODES)
D7001
307 248 2408
ZENER DIODE EDZ7.5B
D7002
307 248 2408
ZENER DIODE EDZ7.5B
D7003
307 248 2408
ZENER DIODE EDZ7.5B
D7004
307 248 2408
ZENER DIODE EDZ7.5B
D7005
307 248 2408
ZENER DIODE EDZ7.5B
D7006
307 248 2408
ZENER DIODE EDZ7.5B
D7007
307 248 2408
ZENER DIODE EDZ7.5B
D7008
307 248 2408
ZENER DIODE EDZ7.5B
D7009
307 248 2408
ZENER DIODE EDZ7.5B
D7010
307 248 2408
ZENER DIODE EDZ7.5B
D7011
408 064 9807
DIODE XBS104S13-R
D7012
408 064 9807
DIODE XBS104S13-R
D8002
407 267 4503
DIODE RB050M-30
D8102
307 206 6301
ZENER DIODE UDZS5.1B-TE17
D8302
307 248 2408
ZENER DIODE EDZ7.5B
D8303
307 248 2408
ZENER DIODE EDZ7.5B
(INDUCTORS)
L7001
945 020 1869
INDUCTOR,750 OHM
L7002
645 102 4015
IMPEDANCE,90 OHM P
L8001
645 101 6805
INDUCTOR,10U M
470 DC 1/16W
(N.S.P)
24
LOCATION PARTS NO.
DESCRIPTION
L8002
945 048 5757
IMPEDANCE,120 OHM P
L8101
645 101 6805
INDUCTOR,10U M
L8102
945 048 5757
IMPEDANCE,120 OHM P
L8301
645 066 1969
INDUCTOR,2.0U M
L8501
645 098 4594
INDUCTOR,4.7U N
L8521
645 098 4594
INDUCTOR,4.7U N
L8541
645 098 4594
INDUCTOR,4.7U N
(CAPACITORS)
C7003
303 419 8903
CERAMIC
C7006
303 338 0309
CERAMIC
C7007
303 276 1000
CERAMIC
C7010
303 338 0309
CERAMIC
C7011
303 338 0309
CERAMIC
C7014
303 338 0309
CERAMIC
C7015
303 409 3406
CERAMIC
C7016
303 409 3406
CERAMIC
C7017
303 409 3406
CERAMIC
C7018
303 409 3406
CERAMIC
C7019
303 276 1307
CERAMIC
C7020
303 276 1307
CERAMIC
C7101
303 381 8109
CERAMIC
C7102
303 381 8109
CERAMIC
C7103
303 381 8109
CERAMIC
C7105
303 433 1102
CERAMIC
C7106
303 384 4702
TA-SOLID
C7107
303 388 6603
TA-SOLID
C7108
303 384 4702
TA-SOLID
C7109
303 388 6603
TA-SOLID
C7110
303 384 4702
TA-SOLID
C7111
303 388 6603
TA-SOLID
C8001
403 455 1606
CERAMIC
C8002
403 455 1606
CERAMIC
C8003
403 455 1606
CERAMIC
C8004
403 455 1606
CERAMIC
C8005
303 298 9602
CERAMIC
C8006
403 455 1606
CERAMIC
C8007
303 155 1800
CERAMIC
C8008
303 281 5000
CERAMIC 0.033U K 25V
C8009
303 155 1800
CERAMIC
C8010
304 093 0108
POS-SOLID 100U M 6.3V
C8013
303 408 5500
CERAMIC
C8014
303 433 1102
CERAMIC
C8101
403 455 1606
CERAMIC
C8102
403 455 1606
CERAMIC
C8103
403 455 1606
CERAMIC
C8104
403 455 1606
CERAMIC
C8105
303 298 9602
CERAMIC
C8106
403 455 1606
CERAMIC
C8107
303 155 1800
CERAMIC
C8108
303 281 5000
CERAMIC 0.033U K 25V
C8109
303 155 1800
CERAMIC
C8110
304 093 0108
POS-SOLID 100U M 6.3V
C8111
304 093 0108
POS-SOLID 100U M 6.3V
C8113
303 384 6409
CERAMIC
C8114
303 433 1102
CERAMIC
C8301
303 338 0309
CERAMIC
C8302
303 338 0309
CERAMIC
C8303
303 346 9806
CERAMIC 0.047U K 10V
C8305
303 381 8109
CERAMIC
C8306
303 393 2607
CERAMIC
C8307
303 276 2106
CERAMIC
C8308
303 393 2607
CERAMIC
C8309
303 308 3408
CERAMIC
C8310
303 320 0706
CERAMIC
C8311
303 376 9401
CERAMIC
C8312
303 215 2204
CERAMIC
C8313
303 376 9401
CERAMIC
C8501
303 384 6409
CERAMIC
C8502
303 384 6508
CERAMIC
C8521
303 384 6409
CERAMIC
C8522
303 384 6508
CERAMIC
C8541
303 384 6409
CERAMIC
C8542
303 384 6508
CERAMIC
(RESISTORS)
R7003
301 224 9009
MT-GLAZE
R7004
301 224 9009
MT-GLAZE
R7005
301 224 9009
MT-GLAZE
R7006
301 224 9009
MT-GLAZE
10U M 6.3V
0.1U K 10V
0.01U K 16V
0.1U K 10V
0.1U K 10V
0.1U K 10V
0.1U K 16V
0.1U K 16V
0.1U K 16V
0.1U K 16V
1000P K 50V
1000P K 50V
1U K 6.3V
1U K 6.3V
1U K 6.3V
1U K 10V
47U M 6.3V
22U M 4V
47U M 6.3V
22U M 4V
47U M 6.3V
22U M 4V
10U K 16V
10U K 16V
10U K 16V
10U K 16V
0.1U K 16V
10U K 16V
0.01U K 25V
0.01U K 25V
2.2U K 16V
1U K 10V
10U K 16V
10U K 16V
10U K 16V
10U K 16V
0.1U K 16V
10U K 16V
0.01U K 25V
0.01U K 25V
4.7U K 6.3V
1U K 10V
0.1U K 10V
0.1U K 10V
1U K 6.3V
22U M 6.3V
3P C 50V
22U M 6.3V
390P K 50V
270P J 25V
1U K 6.3V
0.01U K 50V
1U K 6.3V
4.7U K 6.3V
10U K 6.3V
4.7U K 6.3V
10U K 6.3V
4.7U K 6.3V
10U K 6.3V
10K JA 1/16W
10K JA 1/16W
10K JA 1/16W
10K JA 1/16W
