ELECTRICAL PARTS
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors
MT-FILM
Metallized Film Resistor
MT-GLAZE
Metallized Glaze Resistor
OXIDE-MT
Oxide Metallized Film Resistor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1%
M ..........20%
3. Capacitors
U : µF
P : pF
4. Inductors
UH : µH
MH : mH
5. N.S.P. : Not available as service parts.
LOCATION PARTS NO.
DESCRIPTION
COMPL PWB,CA-2 F/W
613 221 1499
(SEMICONDUCTORS)
Q1001
305 207 1806
TR EMD22
Q1002
405 218 3902
TR UP0431300
OR
305 167 0406
TR EMD12
OR
305 216 2108
TR RN4984FE
Q1003
305 138 6703
TR DTC144EKA
Q1004
305 172 8800
TR 2SC5658-R
OR
305 172 8909
TR 2SC5658-S
OR
305 186 7707
TR 2SC5609 00
Q1005
305 172 8800
TR 2SC5658-R
OR
305 172 8909
TR 2SC5658-S
OR
305 186 7707
TR 2SC5609 00
Q1006
305 172 8800
TR 2SC5658-R
OR
305 172 8909
TR 2SC5658-S
OR
305 186 7707
TR 2SC5609 00
Q1007
305 157 1406
TR 2SA2018
Q1008
305 157 1406
TR 2SA2018
Q1009
305 157 1406
TR 2SA2018
Q1010
405 218 2707
TR UPA650TT-A
Q1011
305 092 4104
TR 2SC4081-R
OR
305 102 5602
TR 2SD1819A-R
Q3004
305 186 7301
TR UP04213 00
OR
305 181 1205
TR NSBC144EDXV6T5
OR
305 173 4009
TR PEMH2
OR
305 166 9509
TR EMH2
(INTEGRATED CIRCUITS)
IC101
409 696 4802
IC EV3HB,BGA (N.S.P)
IC102
410 671 3802
IC K4X51323PG-8GC8,BGA (N.S.P)
IC103
410 671 3802
IC K4X51323PG-8GC8,BGA (N.S.P)
IC106
410 695 7008
IC M95128-WMN6P
IC107
409 694 3005
IC AK8128
IC121
409 703 8403
IC HD MODULE M V1.00-00 J,BGA (N.S.P)
IC301
410 619 9804
IC LC87F2832AUFL68TBM-E,BGA (N.S.P)
IC303
409 684 6801
IC XC61GN2502H-
IC951
410 676 4507
IC LC898200A-TBM-H,BGA (N.S.P)
IC981
309 577 8304
IC LB1906CL-E
(DIODE)
D3003
307 201 7600
LED SML-310MT
(OSCILLATORS)
X1102
645 094 0170
OSC,CRYSTAL 48.00000MHZ
X3001
945 046 1416
OSC,CERAMIC 4.00MHZ
(INDUCTORS)
L1001
945 053 5476
IMPEDANCE,240 OHM P
L1002
945 048 5757
IMPEDANCE,120 OHM P
L1003
945 066 4718
IMPEDANCE,60 OHM P
L1004
945 066 4718
IMPEDANCE,60 OHM P
L1005
945 061 7417
INDUCTOR,47U M
L1006
645 059 7596
IMPEDANCE,90 OHM P
L1007
945 053 5476
IMPEDANCE,240 OHM P
L1008
945 053 5476
IMPEDANCE,240 OHM P
G ............2%
J ............5%
N ..........30%
Z ..........+80% ~ -20%
22
Capacitors
MT-POLYEST Metallized Polyester Capacitor
MT-COMPO
Metallized Composite Capacitor
TA-SOLID
Tantalum Solid Capacitor
AL-SOLID
Aluminum Solid Capacitor
NP-ELECT
Non-Polarized Electrolytic Capacitor
OS-SOLID
Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT
Double Layered Electrolytic Capacitor
POS-SOLID
Polymerized Organic Semiconductor Capacitor
K ............10%
LOCATION PARTS NO.
DESCRIPTION
L1009
945 053 5476
IMPEDANCE,240 OHM P
L1010
945 053 5476
IMPEDANCE,240 OHM P
L1011
945 053 5476
IMPEDANCE,240 OHM P
L1012
945 053 5476
IMPEDANCE,240 OHM P
L1013
945 053 5476
IMPEDANCE,240 OHM P
L1014
945 053 5476
IMPEDANCE,240 OHM P
L1015
945 053 5476
IMPEDANCE,240 OHM P
L1016
945 053 5476
IMPEDANCE,240 OHM P
L1017
945 053 5476
IMPEDANCE,240 OHM P
L1018
945 053 5476
IMPEDANCE,240 OHM P
L1019
945 053 5476
IMPEDANCE,240 OHM P
L1020
945 053 5476
IMPEDANCE,240 OHM P
L1021
945 053 5476
IMPEDANCE,240 OHM P
L1022
945 053 5476
IMPEDANCE,240 OHM P
L1023
945 053 5476
IMPEDANCE,240 OHM P
L1024
945 053 5476
IMPEDANCE,240 OHM P
(CAPACITORS)
C1001
303 384 6409
CERAMIC
C1002
303 384 6409
CERAMIC
C1004
303 276 1307
CERAMIC
C1005
303 384 6409
CERAMIC
C1006
303 338 0309
CERAMIC
C1007
303 338 0309
CERAMIC
C1008
303 338 0309
CERAMIC
C1010
303 338 0309
CERAMIC
C1012
303 381 8109
CERAMIC
C1013
303 381 8109
CERAMIC
C1014
303 338 0309
CERAMIC
C1016
303 338 0309
CERAMIC
C1017
303 338 0309
CERAMIC
C1020
303 338 0309
CERAMIC
C1021
303 384 6409
CERAMIC
C1022
303 338 0309
CERAMIC
C1023
303 338 0309
CERAMIC
C1025
303 338 0309
CERAMIC
C1026
303 381 8109
CERAMIC
C1027
303 381 8109
CERAMIC
C1028
303 338 0309
CERAMIC
C1029
303 338 0309
CERAMIC
C1030
303 338 0309
CERAMIC
C1033
303 384 6409
CERAMIC
C1036
303 381 8109
CERAMIC
C1038
303 338 0309
CERAMIC
C1040
303 338 0309
CERAMIC
C1041
303 338 0309
CERAMIC
C1043
303 384 6409
CERAMIC
C1044
303 338 0309
CERAMIC
C1048
303 338 0309
CERAMIC
C1051
303 338 0309
CERAMIC
C1052
303 338 0309
CERAMIC
C1053
303 338 0309
CERAMIC
C1054
303 338 0309
CERAMIC
C1057
303 338 0309
CERAMIC
C1058
303 338 0309
CERAMIC
4.7U K 6.3V
4.7U K 6.3V
1000P K 50V
4.7U K 6.3V
0.1U K 10V
0.1U K 10V
0.1U K 10V
0.1U K 10V
1U K 6.3V
1U K 6.3V
0.1U K 10V
0.1U K 10V
0.1U K 10V
0.1U K 10V
4.7U K 6.3V
0.1U K 10V
0.1U K 10V
0.1U K 10V
1U K 6.3V
1U K 6.3V
0.1U K 10V
0.1U K 10V
0.1U K 10V
4.7U K 6.3V
1U K 6.3V
0.1U K 10V
0.1U K 10V
0.1U K 10V
4.7U K 6.3V
0.1U K 10V
0.1U K 10V
0.1U K 10V
0.1U K 10V
0.1U K 10V
0.1U K 10V
0.1U K 10V
0.1U K 10V
