INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUEL D'INSTRUCTIONS
Color CCD Camera
CCD-Farbkamera
Caméra CCD couleurs
CCD
About this manual
Before installing and using the camera, please read this manual
carefully. Be sure to keep it handy for later reference.
Über diese Bedienungsanleitung
Lesen Sie bitte vor der Montage und dem Inbetriebnehmen der
Kamera zuerst diese Bedienungsanleitung sorgfältig durch und
bewahren Sie sie zum späteren Nachschlagen auf.
À propos de ce manuel
Avant d'installer et d'utiliser la caméra, veuillez lire ce manuel
attentivement. Gardez-le à portée de main pour toute référence
ultérieure.
VCC-WD8575P

Advertisement

Table of Contents
loading

Related Manuals for Sanyo VCC-WD8575P

Summary of Contents for Sanyo VCC-WD8575P

  • Page 1 INSTRUCTION MANUAL VCC-WD8575P BEDIENUNGSANLEITUNG MANUEL D’INSTRUCTIONS Color CCD Camera CCD-Farbkamera Caméra CCD couleurs About this manual À propos de ce manuel Before installing and using the camera, please read this manual Avant d’installer et d’utiliser la caméra, veuillez lire ce manuel carefully.

  • Page 2: Table Of Contents

    Contents Precautions ..........Adjusting Synchronization Error.
  • Page 3 Contents Specifying Alarm Input........38 Characteristics ALARM IN SETTING .

  • Page 4: Precautions

    Do not open the cabinet, as it may be dangerous and cause damage to the unit. For repairs, consult your dealer or an Authorized Sanyo Service • Dirt can be removed from the cabinet by wiping it with a soft cloth. To Center.

  • Page 5: Dimensions

    Dimensions 15.4 1/4”-20 UNC 24.4 (Unit: mm) English...

  • Page 6: Connection Examples And Peripheral Devices (Sold Separately)

    Connection Examples and Peripheral Devices (Sold separately) For Camera Setup Only Monitor Camera Monitor Camera Digital Video Recorder Records Images Camera Control Unit Monitor Camera Control Unit (VAC-70) Simplified remote controller for camera settings. Monitors images from the camera. Note: Also available as settings screen.

  • Page 7: Part Names

    Part Names Rear Panel Power Indicator (POWER) Video Output Terminal (VIDEO OUT) Illuminates red when power is supplied. Connects to the Video Input Terminal (VIDEO IN) of the monitor or the recorder. See page 9. VIDEO OUT ALARM Alarm I/O Terminal POWER (ALARM IN, OUT, COM) Connects with an external alarm...

  • Page 8: Side Panel

    Part Names Side Panel CURSOR Lens Iris Output Terminal (LENS) Connects with the lens plug of the auto iris type lens (sold separately). (See next page) Bracket CURSOR Button SET Button Moves the cursor during each Used for viewing, switching over and setting.

  • Page 9: Installing Lens

    Installing Lens You are recommended to use any DC type and CS mounting lens equipped with an auto iris. Note: • Apply adapter ring (sold separately) when you use any C mounting lens. • Use any lens of which length (L: see the figure to the right) of the mounting screw is within 5 mm; otherwise you may fail to install or damage the lens.

  • Page 10: Connecting Devices

    Connecting Devices Note: • All the power supplied to the system should be turned off when you connect devices. • Incorrect connections may cause failure and/or smoking; carefully read this and other instruction manuals for each device for proper connections. Basic Connection and Power Connection Connect the Video Output Terminal (VIDEO OUT) Connect the power cord and insert the plug of...

  • Page 11: Connecting Alarm Devices

    Connecting Devices Connecting Alarm Devices Connect the unit with External Alarm or Beeper. External Beeper or Indicator External Alarm Switch or IR Sensor ALARM Note: For alarm device connection, configure an alarm setting for this unit. See pages 38 and 44. English...

  • Page 12: Installing Camera

    Connecting Devices Installing Camera Install the camera in a correct location so that the intended object can be monitored properly. You should also adjust on the monitor side. • You can change the bracket topside down, depending on the installation spot for the camera (see below). Note: •...

  • Page 13: Adjusting Flange Back

    Connecting Devices Adjusting Flange Back Flange back adjustment may be required to correct a focal distance error generated due to attachment thickness of the installed lens. Normally you do not have to make any adjustment, however, you can adjust focus of the installed lens with auto iris, when it provides images out of focus at the maximum telephoto position.

  • Page 14: Overview Of Settings And Adjustments

    Overview of Settings and Adjustments You can configure various adjustments and preference settings on the monitor screen. CURSOR Button Buttons used for settings Press the button up and down or side to side to select an item or set up. •...

  • Page 15: Basic Operation For Settings And Adjustments

    Basic Operation for Settings and Adjustments An Example for Basic Operation for Settings and Adjustments Indicates to press the Indicates to press the Indicates to press the SET CURSOR button up and CURSOR button side to button for decision. down to select an item. side to switch over to other values.

  • Page 16: Selecting Display Language

    Selecting Display Language For accessing the MAIN MENU, see page 13 – 14. You can change the language displayed on the settings and adjusting screens. (Default setting: ENGLISH) LANGUAGE MAIN MENU LANGUAGE ENGLISH LANGUAGE TITLE LANGUE FRENCH SYNC SPRACHE GERMAN EXPOSURE DAY/NIGHT AUTO...

  • Page 17: Naming Cameras

    Naming Cameras For accessing the MAIN MENU, see page 13 – 14. You can give a name (title) to each camera. The specified names are displayed on the monitor ROOM2 so that you can easily distinguish the monitoring images when you use multiple cameras. ROOM1 TITLE SETTING MAIN MENU...
  • Page 18 Naming Cameras Select “POSITION” – “SET” and press the SET On the monitor screen, determine the location button. where the name should be displayed by pressing the button up-down or side to side; and then press the SET button. TITLE SETTING ABCDEFGHIJKLM NOPQRSTUVWXYZ CAM1...

  • Page 19: Adjusting Synchronization Error

    Adjusting Synchronization Error For accessing the MAIN MENU, see page 13 – 14. By default, the synchronization adjustment for the camera is performed internally (INT). However, you must make adjustments in the Line Lock (L-L) Setting screen, if the monitor screen seems out of sync after switching over among multiple cameras using AC 24 V.

  • Page 20: Adjusting Auto Iris

    Adjusting Auto Iris For accessing the MAIN MENU, see page 13 – 14. This unit is designed to accept the DC type auto iris lens (sold separately) and is factory-configured to be ready-for-use with the optional lens. However, you can configure and/or make adjustments for preferred brightness depending on the environment, condition or other optional lens you use.
  • Page 21 Adjusting Auto Iris IRIS SETTING (AI: Auto Iris) (continued) Select “IRIS STOP” and specify an iris value Set “MENU” to “END” and press the SET button. (0 – 17). RFinishes the settings screen and returns to the normal monitoring screen. •...

  • Page 22: Adjusting Electronic Iris (For Manual Or Fixed Iris Lens)

    Adjusting Electronic Iris (For Manual or Fixed Iris Lens) For accessing the MAIN MENU, see page 13 – 14. If you need to adjust the brightness for using manual iris lens or fixed iris lens, follow the steps below. • Adjust the iris manually. MAIN MENU EXPOSURE SETTING LANGUAGE...

  • Page 23: Correcting Backlight

    Correcting Backlight For accessing the MAIN MENU, see page 13 – 14. If the images of subjects are not clear because of backlight, correct it by adjusting conditions or changing correction method. MAIN MENU EXPOSURE SETTING LANGUAGE IRIS WIDE-D TITLE SYNC EXPOSURE SENSE UP...

  • Page 24: Cent (Blc Setting) (Center-Weighted Metering)

    Correcting Backlight CENT (BLC SETTING) (Center-weighted Metering) Locate the upper left corner of an area for which Specify the correction area size, and press the you want to correct backlight, and then press the SET button. SET button. BLC SETTING BLC SETTING [SIZE] [POSITION]...
  • Page 25 Correcting Backlight CENT (BLC SETTING) (Center-weighted Metering) (continued) To correct areas other than center, select from Specify a metering level (0 – 15). the options. BLC WINDOW WEIGHTING BLC WINDOW WEIGHTING BOTTOM LEFT BOTTOM RIGHT LEFT CENTER[FIX] RIGHT CENTER[FIX] PRESET MENU BACK PRESET...

  • Page 26: Mult (Blc Setting) (Multi-Spot Metering)

    Correcting Backlight MULT (BLC SETTING) (Multi-spot Metering) Select an item and specify each level (0 – 15). Set “MENU” to “END” and press the SET button. RFinishes the settings screen and returns to the normal monitoring screen. BLC SETTING • If you want to return to the previous screen, select “BACK” and [BLC WEIGHT] press the SET button.

  • Page 27: Setting Wide Dynamic Range

    Setting Wide Dynamic Range For accessing the MAIN MENU, see page 13 – 14. Correction is made for simultaneous monitoring of subjects which are different in brightness, one in a dark room and another in bright outdoor environment, for example. EXPOSURE SETTING MAIN MENU LANGUAGE...
  • Page 28 Setting Wide Dynamic Range Set “MENU” to “END” and press the SET button. About Wide Dynamic Range RFinishes the settings screen and returns to the normal Brighter parts of an image are white-saturated, while darker monitoring screen. parts black-saturated, when the difference between •...

  • Page 29: Increasing Electronic Sensitivity

    Increasing Electronic Sensitivity For accessing the MAIN MENU, see page 13 – 14. If subject images are not very clear due to ambient darkness, you can increase the camera sensitivity by specifying the “SENSE UP” (increasing electronic sensitivity) option. Note: If you specify this option, the exposure time of CCD will be extended as it grows dark. Thus, for moving subjects, the images may be associated with obtrusive residual vision or blurring.

  • Page 30: Specifying Shutter Speed

    Specifying Shutter Speed For accessing the MAIN MENU, see page 13 – 14. You can specify the electronic shutter speed to capture fast-moving subjects. Note: With the increase in shutter speed number, faster movement can be captured, though the image becomes darker. MAIN MENU EXPOSURE SETTING LANGUAGE...

  • Page 31: Adjusting Day/Night Function

    Adjusting DAY/NIGHT Function For accessing the MAIN MENU, see page 13 – 14. The DAY/NIGHT function automatically switches over between COLOR and B/W mode depending on the ambient brightness; for example, choosing COLOR mode during daytime, and B/W mode for nighttime monitoring with its increased sensitivity in a darker environment.

  • Page 32: D/N Setting-Auto

    Adjusting DAY/NIGHT Function D/N SETTING-AUTO Select “AGC MAX GAIN” and specify the Select “LEVEL” and specify a level for DAY/ maximum value of gain for AGC* NIGHT switching. : Switches in darker conditions; i.e., color shot is preferred D/N SETTING - AUTO so that it does not switch form COLOR to B/W until it gets very dark.

  • Page 33: D/N Setting-Color

    Adjusting DAY/NIGHT Function D/N SETTING-COLOR Select “AGC MAX GAIN” and specify the GAIN SETTING Select “OFF” and press the SET button, and you can specify a value maximum value of gain for AGC*. for the fixed gain. (0 – 7) D/N SETTING - COLOR GAIN SETTING AGC MAX GAIN...

  • Page 34: D/N Setting-B/W (Black And White)

    Adjusting DAY/NIGHT Function D/N SETTING-B/W (Black and white) Select “AGC MAX GAIN” and specify the GAIN SETTING Select “OFF” and press the SET button, and you can specify a value maximum value of gain for AGC* for the fixed gain. (0 – 7) D/N SETTING - B/W GAIN SETTING AGC MAX GAIN...

  • Page 35: Adjusting White Balance

    Adjusting White Balance For accessing the MAIN MENU, see page 13 – 14. With its default Auto-tracing White Balance (ATW) setting, this unit is able to MAIN MENU obtain natural colors even when the light source is changed. However, you may LANGUAGE manually change the white balance settings or its mode to obtain better tone, TITLE...

  • Page 36: Atw Masking (Masking For Atw)

    Adjusting White Balance ATW MASKING (Masking for ATW) Select an area to be masked and specify “ON”. Set “MENU” to “END” and press the SET button. RFinishes the settings screen and returns to the normal monitoring screen. ATW MASKING • If you want to return to the previous screen, select “BACK” and press the SET button.

  • Page 37: Awc Setting (One-Push Adjustment)

    Adjusting White Balance AWC SETTING (One-Push Adjustment) Select “AWC LOCK” – “SET”. To perform fine adjustment of color In the “AWC SETTING” screen, select “GO TO MWB” – “SET”, and press the SET button. AWC SETTING R The “MWB SETTING” screen appears. Specify values manually. (See page 37) AWC LOCK MEMO: Transferring to the “MWB SETTING”...

  • Page 38: Mwb Setting (Manual White Balance)

    Adjusting White Balance MWB SETTING (Manual White Balance) Select “R” or “B” to adjust tint (0 – 255). Set “MENU” to “END” and press the SET button. RFinishes the settings screen and returns to the normal MWB SETTING monitoring screen. •...

  • Page 39: Specifying Alarm Input

    Specifying Alarm Input For accessing the MAIN MENU, see page 13 – 14. If you have connected an external door switch or an infrared sensor to the alarm input terminal (ALARM IN) on the rear panel, specify the following settings. (For connecting alarm devices, see page 10; for the “Alarm Output” settings, see page 44). This unit has a built-in motion sensor, which outputs alarm signals when any moving subject, such as would be intruder, is detected.
  • Page 40 Specifying Alarm Input Select “MASKING” and specify “ON” and press Select a masking area and specify “ON”. the SET button. MOTION MASKING MOTION SETTING MASKING BOTTOM SENSITIVITY LEFT DURATION RIGHT CENTER PRESET MENU BACK PRESET MENU BACK RMasking will be applied for the area specified with “ON”. •...
  • Page 41 Specifying Alarm Input Select “SENSITIVITY” – “SET” and press the SET Select “Y-DIFFER” and specify a luminance button. difference level (1 – 10). • The greater the number, the lower the responsiveness to the brightness variation, such as lighting on or off conditions. MOTION SETTING MASKING SENSITIVITY...
  • Page 42 Specifying Alarm Input Select “DURATION” and specify a time until the Select “POLARITY” and specify a polarity for the next alarm input becomes enabled. signal. ALARM IN SETTING MOTION SETTING MASKING MODE POLARITY SENSITIVITY DURATION MOTION MOTION SET ZOOM ZOOM TIME DURATION PRESET NO : Normal Open (When closed, alarm input is detected.)
  • Page 43 Specifying Alarm Input Select “ZOOM” and specify the zoom factor for Select “ZOOM TIME” and specify duration time alarm detection. for zooming (if you specified “ZOOM” to other than “OFF” in step M). ALARM IN SETTING • Select from: 5S, 10S, 15S, 20S, 30S, 1M, 2M, 3M, 4M or 5M (S = second, M = minute) MODE POLARITY...

  • Page 44: Using Alarm Input Terminal As Day/Night Switching

    Specifying Alarm Input Using Alarm Input Terminal as DAY/NIGHT Switching Set “MODE” to “COLOR”. Select “POLARITY” and specify a polarity for the signal. ALARM IN SETTING Between ALARM POLARITY MODE COLOR IN and COM Mode Setting POLARITY Terminals MOTION MOTION SET Open COLOR ZOOM...

  • Page 45: Specifying Alarm Output

    Specifying Alarm Output For accessing the MAIN MENU, see page 13 – 14. If you have connected an external beeper or indicator to the alarm output terminal (ALARM OUT) on the rear panel, specify the following settings. You can also obtain a notification on the screen while an alarm occurs. (For connecting alarm devices, see page 10.) ALARM SETTING MAIN MENU...

  • Page 46: Alarm Sign (Alarm Display)

    Specifying Alarm Output ALARM SIGN (Alarm display) Select “ALARM SIGN” on the “ALARM SETTING” Set “MENU” to “END” and press the SET button. screen and specify a displaying time. RFinishes the settings screen and returns to the normal monitoring screen. •...

  • Page 47: Correcting Gamma Characteristic

    Correcting Gamma Characteristic For accessing the MAIN MENU, see page 13 – 14. If the contrast or brightness of the monitor screen does not seem appropriate, change the mode for Gamma correction*. OPTION MAIN MENU GAMMA 0.45 LANGUAGE APERTURE TITLE MIRROR SYNC NEGA/POSI...

  • Page 48: Accentuating Subject Outline

    Accentuating Subject Outline For accessing the MAIN MENU, see page 13 – 14. By specifying the APERTURE* setting, you can accentuate the outline of the subject when its image is blurred and unidentifiable. MAIN MENU OPTION LANGUAGE GAMMA 0.45 TITLE APERTURE SYNC MIRROR...

  • Page 49: Inverting Images (Horizontal/Vertical)

    Inverting Images (horizontal/vertical) For accessing the MAIN MENU, see page 13 – 14. If a camera is installed upside down, or monitoring subjects in a mirror or viewing backward from vehicle, you can invert the images vertically and/or horizontally. MAIN MENU OPTION LANGUAGE GAMMA...

  • Page 50: Inverting Images (Brightness/Hue)

    Inverting Images (Brightness/Hue) For accessing the MAIN MENU, see page 13 – 14. You can record negative images of color film as positive images by reflecting the brightness and hue of the video signal. MAIN MENU OPTION LANGUAGE GAMMA 0.45 TITLE APERTURE SYNC...

  • Page 51: Hiding Partial Image (Privacy Protection)

    Hiding Partial Image (Privacy Protection) For accessing the MAIN MENU, see page 13 – 14. If privacy protection is required for any shot, apply the masking feature for any position to be prevented from being presented. You can also lock the setting and its cancellation by specifying a password. MAIN MENU OPTION LANGUAGE...
  • Page 52 Hiding Partial Image (Privacy Protection) PRIVACY MASK SETTING (continued) Locate the upper left corner of an area for which • From the datum point at the upper left corner of the area, the size can be scaled up or down, as well as side to side. you want to mask, and then press the SET RThe “PRESET”...
  • Page 53 Hiding Partial Image (Privacy Protection) To lock (protect) the settings: Enter the password (4 numerical values) and press the SET button. Select “PASSWORD LOCK” – “OFF” and press the SET button. PASSWORD PRIVACY MASK SETTING PASSWORD LOCK 1234 PASSWORD CHANGE SET MASK SET Select Move...
  • Page 54 Hiding Partial Image (Privacy Protection) To change password: Enter the current password and press the SET button. Select “PASSWORD CHANGE” – “SET” and press the SET button. PASSWORD PRIVACY MASK SETTING [NOW PASSWORD] PASSWORD LOCK 1234 PASSWORD CHANGE SET MASK SET MENU BACK MENU...

  • Page 55: Multiplying Magnitude Of Electronic Zoom

    Multiplying Magnitude of Electronic Zoom For accessing the MAIN MENU, see page 13 – 14. In addition to zooming on the lens side, you can obtain further zooming by magnifying an electronic zoom factor. MAIN MENU OPTION LANGUAGE GAMMA 0.45 TITLE APERTURE SYNC...

  • Page 56: Settings Screens List

    Settings Screens List For accessing the MAIN MENU, see page 13 – 14. [LANGUAGE] [WHITE BALANCE] LANGUAGE : Switches display language among English, German and (ATW/ATW-A/AWC/3200/5600/FLUE/MWB) : Selects mode for white French. (See page 15) balance. (See page 34) ATW MASKING : Specifies mask for auto mode. (See page 35) [TITLE] AWC SETTING : Adjusts through one-touch by focusing on white TITLE SETTING : Names camera.
  • Page 57 Settings Screens List Useful Operations PRIVACY MASK • Putting titles to camera images: PRIVACY MASK SETTING TITLE SETTING (See page 16). PASSWORD LOCK : Locks the mask settings by password. (See page 52) • Capturing clear image of fast-moving subject by increasing shutter PASSWORD CHANGE : Specifies a new password.

  • Page 58: Troubleshooting

    Troubleshooting Before seeking repair service, please review the following points first. If the trouble persists, contact your local sales agent or installer. Symptom Items to Be Checked Symptom Items to Be Checked • Is the coaxial cable connected securely? Distorted picture after •...

  • Page 59: Specifications

    Specifications Pickup device 1/3” CCD Privacy masking OFF/ON, Up to 8 spots, Lockable with password Effective pixels 752 (H) x 582 (V), PAL AUTO / COLOR / B/W, specifiable COLOR / B/W switching sensitivity for AUTO mode, switchable Horizontal resolution More than 480 TV lines DAY/NIGHT COLOR / B/W mode working with external terminal...
  • Page 60 Printed on recycled paper Gedruckt auf recyceltem Papier PapierImprimé sur du papier recyclé SANYO Electric Co., Ltd. 1AC6P1P2918-- L5BC2/XE (0305KP-SY) Pri nt ed in Japan...
