Sanyo VCC-HD5600P Setup Manual

Security camera sysytem
Hide thumbs

Advertisement

SUMMARY/SETUP MANUAL Power Board Unit
THIS INSTALLATION SHOULD BE MADE
BY A QUALIFIED SERVICE PERSON AND
SHOULD CONFORM TO ALL LOCAL
CODES.
(Power Boad Unit)
(Megapixel Camera)
VA-94S
Megapixel Camera
VCC-MCH5600
VCC-MCH5600P
Before installing and using the camera, please read
this manual carefully.
Be sure to keep it handy for later reference.
In addition, be sure to read carefully the electronic
manual (INSTRUCTION MANUAL) contained in the
supplied CD-ROM to ensure correct operation of
the camera.
Important
Be careful when opening holes for installing
the unit. Work with the power and video cables
pulled out for easy installation.
Make sure to properly perform waterproofi ng for
the ceiling where you are installing the unit.
Make sure that the surface in the installation
location has no unevenness and is strong
enough to bear the total weight of the unit.
Install this unit in an environment where the
temperature range stays between –10°C and
+50°C/14°F and 122°F (no condensation
allowed).
As a precaution against static electricity
damage, touch a nearby metal object (door
knob, etc.) to dissipate static electricity in your
body before touching this unit.

Advertisement

loading

  Also See for Sanyo VCC-HD5600P

  Related Manuals for Sanyo VCC-HD5600P

  Summary of Contents for Sanyo VCC-HD5600P

  • Page 1 SUMMARY/SETUP MANUAL Power Board Unit THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE PERSON AND SHOULD CONFORM TO ALL LOCAL CODES. (Power Boad Unit) (Megapixel Camera) VA-94S Megapixel Camera VCC-MCH5600 VCC-MCH5600P Before installing and using the camera, please read this manual carefully.
  • Page 2: Table Of Contents

    Contents Name and Function of Each Component ... 2 Installation ... 3 Connections ... 5 Control/Address Settings ... 9 Address Settings Table... 10 Network Settings ... 11 Specifications ... 12 Copyright Notice ... 14 ■ Accessories • Camera Unit ① Surface cover ②...
  • Page 3: Name And Function Of Each Component

    Name and Function of Each Component This device is composed of a camera unit and power unit (VA-94S). ③ Ⓐ Ⓑ ⑧ ① Connection Point This is the connection point between the camera unit and the power unit. ② Interface Board (accessories) Control switch (transmission rate and protocol setting, etc.) Address switch (control camera address setting) Control terminal (connection of controller and alarm input/output cable)
  • Page 4: Installation

    Installation 1. Installing the power board unit Place the supplied pattern sheet on the ceiling, mark the locations and drill the holes for the cables and screws. • Pull out the cables from the ceiling. Attach the supplied dust sheet (A) to the base of the power board unit and the detachable piece of the sheet (B) to the side.
  • Page 5: Mounting The Camera Unit

    2. Mounting the camera unit Fasten the camera unit safety wire (E) to the hook (F) on the inner side of the power board unit. Align the colored dot (blue) on the camera unit with the arrow on the power board unit, and push the camera unit until they click.
  • Page 6: Connections

    Connections ■ VCC-MCH5600 • Before attempting the following connections, be sure to turn off all components of your system. • Improper connection may cause smoke or failures. Before attempting to connect each system component, carefully read the instruction manual that comes with it to familiarize yourself with the correct connection procedure.
  • Page 7 ■ VCC-MCH5600P • Before attempting the following connections, be sure to turn off all components of your system. • Improper connection may cause smoke or failures. Before attempting to connect each system component, carefully read the instruction manual that comes with it to familiarize yourself with the correct connection procedure.
  • Page 8 Connections Network Connection This camera is designed so that you can use all of its functions via network operation. By connecting the network (LAN) socket of the camera to your PC using a LAN cable, you can configure and operate it from the Web browser installed on your PC. LAN connection Switching hub •...
  • Page 9 OUT2 OUT1/2 OUT1 IN 1-8 485B 485A White ❶ Outputting Alarm Signals (OUT 1-2) Connect a buzzer, lamp, or other alarm device to the alarm output cable. Alarm can be output via two channels. • After connecting an alarm device, configure the output conditions for the corresponding alarm output terminal (ALARM OUT1 or 2) via network operation on the ALARM SETTINGS screen.
  • Page 10: Control/Address Settings

    For further information, refer to the “Address Settings Table” on the next page. Switch 1 Switch 2 Corresponding Protocol Automatic switching between Sanyo SSP and high speed SSP Automatic switching between PELCO-D and PELCO-P ❶ ❷ ❶ ❷ ❸ ❸...
  • Page 11: Address Settings Table

    Available address: 1 – 255 • When you set the address to 128 – 255, make sure to turn Switch 8 “ON”. Address (Camera No.) Switch No. Protocol SANYO/PELCO PELCO 1 2 3 4 5 6 7 – ○ ○ ○ ○ ○ ○...
  • Page 12: Network Settings

    Network Settings Preparing Your Computer for Network Operation Check your operating environment. ( Connect the camera to the network to which your PC is also connected. Configue the network information on your PC. Configure information such as the IP address of your PC. Install the “H.264 Plug-in”...
  • Page 13: Specifications

    ON/OFF English, French, German, Spanish, Japanese Monitor output terminal (BNC) 10BASE-T/100BASE-TX (RJ-45 connector) For connecting SANYO-specified external hard disk case (VA-HDC4000) 1 (SDHC compliant, max. 32 GB supported) 8 (NO/NC), also serving as Day/Night switching terminal <control terminal> 2 (NO/NC switching, 16 V, 150 mA, open collector) <control terminal>...
  • Page 14 Specifications ■ Recording media SD memory card/ External HDD For the recommended SD memory cards, visit our website. http://www.sanyo-cctv.net/ ■ Network Image/video compression Video size (H.264) Video size (JPEG) Picture quality Interface Protocol Audio Simultaneous access Security ■ Dimensions/Weight 192 (7.56) Appearance and specifications are subject to change without prior notice or obligations.
  • Page 15: Copyright Notice

    Copyright Notice The instruction manual and the software are copyrighted by SANYO Electric Co., Ltd. No materials contained in the manual and the software may, wholly or partially, be copied, modified, reproduced, or distributed in any format without the prior permission of the copyright holder.
  • Page 16 1AC6P1P4031-- SANYO Electric Co., Ltd. L9EBQ/WA, L5DD2/XE, US (1009KR)
