FRONT PANEL INDICATORS
POWER ON INDICATOR: The power light will glow blue
1.
when power is applied.
MIC 1 & MIC 2: Mic link and registration indicators
2.
a. Flashing amber indicates registration is in process.
b. Solid green indicates a link has been established.

TOP PANEL CONTROLS

1. MIC VOLUME: Controls the volume level of the
microphones.
2. TONE CONTROL: Adjusts the audio tone, adding
more bass or treble for a more rich or crisp sound.
2 1 2
1 POWER 2
1 2
MICROPHONE TONE
MIN MAX TREBLE BASS
VOLUME
7
