4.2

Rear view

Item Symbol Description
1
2
HF
HF
3
COM
4
5
6
7
099-000124-EW501
29.07.2011
1
6
0
Main switch, machine on/off
Ignition type changeover switch
HF
= Liftarc (contact ignition)
= HF ignition
HF
PC interface, serial (D-Sub connection socket, 9-pole)
G¼" connecting nipple
Shielding gas connection on the pressure regulator
Connection socket, 19-pole
Remote control connection
Mains connection cable
Cooling air inlet
Machine description
3
2
4
5
7
Figure 4-2
Rear view
17
