Design and function
Advanced settings
5.11
Advanced settings
5.11.1 Setting slope times for secondary current AMP% or pulse edges
Display
52
Setting/selection
Expert menu
Slope time tS1 (main current to secondary current)
Setting: 0.00 s to 20.0 s (factory setting 0.01 s)
Slope time tS2 (secondary current to main current)
Setting: 0.00 s to 20.0 s (factory setting 0.01 s)
Figure 5-23
Figure 5-24
099-000124-EW501
29.07.2011
