Chapter 2. Setting Up the Express 3100

EXPRESS 3100 PHYSICAL DESCRIPTION

This section describes the Front and Rear Panels of the Express 3100.

Front Panel

The Express 3100 Front Panel contains five LEDs associated with the
DTE port and the ISDN interface (see Figure 2-1). Table 2-1 describes
the LEDs.
1 2
TD RD PWR
Express 3100 PHONE LINE

Figure 2-1. Front Panel LEDs

61200240L2-20 Express 3100 User Manual 2-7
