UPGRADING SOFTWARE USING
HYPERTERMINAL
Instructions for Upgrading Software Using HyperTerminal
Step
1
Download the necessary upgrade files from the
ADTRAN web site ( www.adtran.com ).
2
Connect to the Express 3100 via HyperTerminal:
a. Windows 95
Start > Programs> Accessories > HyperTerminal
Windows 98
Start > Programs> Accessories > Communication
> HyperTerminal
b. When the Connection Description window opens,
type in a connection name, select an icon, and click
OK.
c. In the Connect To window, go to the Connect using
field and select the COM port to which the Express
3100 is connected; click OK.
d. The COM port Properties window opens next.
Change the Bits per second field to 57600 and click
OK.
3
Type AT!FLASHLOAD to initiate the firmware update.
The AT command is not visible since echo is off by de-
fault. (To enable echo, type ATE1 .)
4
Click the Transfer menu; then click Send File....
5
Click Browse to locate the directory and file to download
to the Express 3100.
61200240L2-20
Chapter 6. Upgrading Software
Action
Express 3100 User Manual
6-3
