Layer 3 IP Networking

Layer 3 Global Advanced Settings

The L3 Global Advanced Settings window allows the user to enable and disable Layer 3 settings and functions from a
single window. The full settings and descriptions for these functions will appear later in this section. To view this window,
open the Configuration folder and then the Layer 3 IP Networking folder and click on the L3 Global Advanced
Settings link to access the following window.
The user may set the following:
Parameter
DVMRP State
PIM-DM State
RIP State
OSPF State
ARP Aging Time
xStack DES-6500 Modular Layer 3 Chassis Ethernet Switch User Manual
Figure 6- 105. L3 Global Advanced Settings window
Description
The user may globally enable or disable the Distance Vector Multicast Routing Protocol
(DVMRP) function by using the pull down menu.
The user may globally enable or disable the Protocol Independent Multicast - Dense
Mode (PIM-DM) function by using the pull down menu.
The user may globally enable or disable the Routing Information Protocol (RIP) function
by using the pull down menu.
The user may globally enable or disable the Open Shortest Path first (OSPF) function
by using the pull down menu.
The user may globally set the maximum amount of time, in minutes, that an Address
Resolution Protocol (ARP) entry can remain in the Switch's ARP table, without being
accessed, before it is dropped from the table. The value may be set in the range of 0-
65535 minutes with a default setting of 20 minutes.
