SSH User Authentication Mode

The following windows are used to configure parameters for users attempting to access the Switch through SSH. To access
the following window, click Security Management > Secure Shell > SSH User Authentication.
In the example screen above, the User Account "Darren" has been previously set using the User Accounts window in the
Security Management folder. A User Account MUST be set in order to set the parameters for the SSH user. To configure
the parameters for a SSH user, click on the hyperlinked User Name in the Current Accounts window, which will reveal
the following window to configure.
The user may set the following parameters:
Parameter Description
User Name Enter a User Name of no more than 15 characters to identify the SSH user. This User
Name must be a previously configured user account on the Switch.
Auth. Mode The administrator may choose one of the following to set the authorization for users
attempting to access the Switch.
Host Based – This parameter should be chosen if the administrator wishes to use a
remote SSH server for authentication purposes. Choosing this parameter requires the
user to input the following information to identify the SSH user.
Password – This parameter should be chosen if the administrator wishes to use an
administrator-defined password for authentication. Upon entry of this parameter, the
Switch will prompt the administrator for a password, and then to re-type the password for
confirmation.
Public Key – This parameter should be chosen if the administrator wishes to use the
publickey on a SSH server for authentication.
Host Name Enter an alphanumeric string of no more than 32 characters to identify the remote SSH
user. This parameter is only used in conjunction with the Host Based choice in the Auth.
Mode field.
Host IP Enter the corresponding IP address of the SSH user. This parameter is only used in
conjunction with the Host Based choice in the Auth. Mode field.
Click Apply to implement changes made.
NOTE: To set the SSH User Authentication parameters on the Switch, a User Account must
be previously configured. For more information on configuring local User Accounts on the
Switch, see the User Accounts section of this manual located in this section.
xStack DES-6500 Modular Layer 3 Chassis Ethernet Switch User Manual
Figure 7- 7. Current Accounts window
Figure 7- 8. SSH User window
Host Name – Enter an alphanumeric string of no more than 32 characters to
•
identify the remote SSH user.
Host IP – Enter the corresponding IP address of the SSH user.
•
192
