1.15 Technical Specifications

Table 3 - Technical Specs

Category
CPU, Memory
Flash, EPROM
Installable Serial
Protocols
Serial Interface
Reset
Power Supply
Dimensions
Weight
Temperature
Humidity
Case
Protocols Supported
Network Interface
Data Rates
Serial Line Formats
Modem Control
Flow Control
Management
System Software
LEDs
Compatibility
Isolation
Agency Approvals
UDS-10 User Guide
Description
AMD 188ES CPU, 25MHz clock, 128kByte RAM
512kByte Flash PROM
Standard Tunnel (UDS-10, and UDS-10-IAP), Modbus (UDS-10-
IAP), DF1 (UDS-10-IAP)
Female DB-25 connector (DCE pinout)
Baud Rate selectable from 300 to 115kBaud
Software selectable RS-232C or RS-422/485
Front panel recessed push button
External adapter for 9-30 VDC, 3 Watts Max
2.3 cm (0.9 in) H, 6.4 cm (2.5 in) W, 9.0 cm (3.5 in) D
204.12g (7.2oz)
Operating range: 5° to +50° C (41to122° F)
Max temperature change per hour: 20° C (36° F)
Storage range: -40° to +66° C (-40 to 151° F)
10% to 90% RH, non-condensing, 40% to 60% recommended
Metal case with mounting flanges. (Not UDS-10B)
Auto IP, ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP,
BOOTP, TFTP, and HTTP
RJ-45 10Base-T Ethernet
300 bps to 115,200 bps
Characters: 7 or 8 data bits
Stop bits: 1,2
Parity: odd, even, none
DTR, DCD, CTS, RTS, DSR
CTS/RTS (hardware)
XON/XOFF (software)
Internal web server (Standard Tunneling only)
SNMP (read only)
Serial login
Telnet login
Windows® 95/98/ME/NT/2000 based configuration software
Link (green), Network transmit/receive (yellow), Collision (red),
Diagnostic (red), Status (green)
Ethernet: Version 2.0/IEEE 802.3
Ethernet: 1500 Vrms, Serial: 2000 Vrms
C/UL, TUV, FCC-B, CE
