3.5.3 Netmask: Number of Bits for Host Part

A netmask defines the number of bits taken from the IP address that are assigned for the host
section.
Note: Class A: 24 bits; Class B: 16 bits; Class C: 8 bits.
The unit prompts for the number of host bits to be entered, then calculates the netmask, which
is displayed in standard decimal-dot notation when the saved parameters are displayed (for
example, 255.255.255.0).

Table 4 - Standard IP Network Netmasks

Network Class
A
B
C

Table 5 - Netmask Examples

Netmask
255.255.255.252
255.255.255.248
255.255.255.240
255.255.255.224
255.255.255.192
255.255.255.128
255.255.255.0
255.255.254.0
255.255.252.0
255.255.248.0
...
255.128.0.0
255.0.0.0
UDS-10 User Guide
Host Bits Netmask
24 255.0.0.0
16 255.255.0.0
8 255.255.255.0
Host Bits
2
3
4
5
6
7
8
9
10
11
...
23
24
Configure
3-13
