Exit Configuration Mode; Get Configuration - Lantronix Device Server UDS 10 User Manual

Configure

3.10 Exit Configuration Mode

Select 8 to exit the configuration mode without saving any changes or rebooting. Select 9 to
save all changes and reboot the device. All values are stored in nonvolatile memory.

3.11 Get Configuration

The device configuration information is stored in flash memory and can be read and saved in
a configuration file (filename.cfg). To get the configuration information, click the Get
Configuration icon button on the Device Management window. The following dialog appears.
The Device IP Address is shown in the first field. This is the device selected in the
DeviceInstaller main window. In the Configuration File field, click the Open File button to
select a filename for the configuration file. Click the Get button and the file information is
read from the device and saved in the selected file.
UDS-10 User Guide 3-27
