Getting Started

2.6 Serial Port Login

If you want to initially configure the unit through a serial connection, follow these steps:
1. Connect a console terminal or PC running a terminal emulation program to your unit's
serial port. The default serial port settings are 9600 baud, 8 bits, no parity, 1 stop bit, no
flow control.
2. To enter Setup Mode, cycle the unit's power (power off and back on). After power-up,
the self-test begins and the red Diagnostic LED starts blinking. You have one second to
enter three lowercase x characters.
Note: The easiest way to enter Setup Mode is to hold down the x key at the terminal (or
emulation) while powering up the unit.
3. At this point, the screen display is the same as when you use a Telnet connection. To
continue with a serial port login, go to Using a Telnet Connection on page 3-10.
2-12 UDS-10 User Guide
