3.6 Channel 1 Configuration (Serial Port Parameters)

Using this option, define how the serial port will respond to network and serial
communications.

Baudrate (9600)

I/F Mode (4C)
Flow (00)
Port No (10001)
ConnectMode (C0)
Remote IP Address : (000).(000).(000).(000)
Remote Port (00000)
DisConnMode (00)
FlushMode
DisConnTime (00:00) :
SendChar 1
SendChar 2
3.6.1 Baudrate
The unit and attached serial device, such as a modem, must agree on a speed or baud rate to
use for the serial connection. Valid baud rates are 300, 600, 1200, 2400, 4800, 9600 (default),
19200, 38400, 57600, and 115200 bits per second.

3.6.2 I/F (Interface) Mode

The Interface (I/F) Mode is a bit-coded byte that you enter in hexadecimal notation.
Note: See Table 35 - Binary to Hexadecimal Conversion Table.

Table 6 - Interface Mode Options

I/F Mode Option
(1)
RS-232C
(1)
RS-422/485
(1)
RS-485 2-wire
7 Bit
8 Bit
No Parity
Even Parity
Odd Parity
1 Stop bit
2 Stop bit
(1) The UDS-10 requires you to choose the correct setting in the IF mode.
UDS-10 User Guide
(00)
(00)
(00)
7 6 5 4
0 0
1 1
0 1
0 1
1 1
3 2 1 0
0 0
0 1
1 1
1 0
1 1
Configure
3-15
