8.3.2 Interface Mode

The Interface (I/F) Mode is a bit-coded byte entered in hexadecimal notation. Use the
following table to select Interface Mode settings:

Table 23 - Interface Mode Options

I/F Mode Option
(1)
RS-232C
(1)
RS-422/485
(1)
RS-485 2-wire
7 Bit
8 Bit
No Parity
Even Parity
Odd Parity
1 Stop bit
2 Stop bits
(1) The UDS-10 requires you to choose the correct setting in the IF mode.
The following table demonstrates how to build some common Interface Mode settings:

Table 24 - Common Interface Mode Settings

Option
RS-232C, 8-bit, No Parity, 1 stop bit
RS-232C, 7-bit, Even Parity, 1 stop bit
RS-485 2-Wire, 8-bit, No Parity, 1 stop bit
RS-422, 8-bit, Odd Parity, 2 stop bits
(1) The UDS-10 requires you to choose the correct setting in the IF mode.
Note: See Table 35 - Binary to Hexadecimal Conversion Table.
UDS-10 User Guide
7
6
5
4
3
1
1
0
0
1
1
0
1
0
1
1
1
(1)
(1)
(1)
(1)
2
1
0
0
0
0
1
1
1
0
1
Binary
Hex
0100 1100
4C
0111 1000
78
0100 1111
4F
1101 1101
DD
UDP
8-9
