The following table demonstrates how to build some common Interface Mode settings:

Table 7 - Common Interface Mode Settings

Common I/F Mode Setting
RS-232C, 8-bit, No Parity, 1 stop bit
RS-232C, 7-bit, Even Parity, 1 stop bit
RS-485 2-Wire, 8-bit, No Parity, 1 stop bit
RS-422, 8-bit, Odd Parity, 1 stop bit
(1) The UDS-10 requires you to choose the correct setting in the IF mode.
3-16
Binary
(1)
0100 1100
(1)
0111 1000
(1)
0100 1111
(1)
0101 1101
Hex
4C
78
4F
5D
