3.7 Expert Settings

Note: You can change these settings via Telnet or serial connections only, not on the Web-
Manager.
Note: The Expert Settings option does not appear with UDS-10-IAP.
These parameters should only be changed if you are an expert
and definitely know the consequences the changes might have.
TCP Keepalive time in s (1s – 65s; 0s=disable): (0)

3.7.1 TCP Keepalive time in s

This option allows you to change how many seconds the unit will wait during a silent
connection before attempting to see if the currently connected network device is still on the
network. If the unit then gets no response, it will drop that connection.

3.8 Security Settings

Note: You can change these settings via Telnet or serial connections only, not on the Web-
Manager. We recommend that you set security over the dedicated network or over the serial
setup. If you set parameters over the network (Telnet 9999), someone else could capture these
settings.
Disable SNMP (N)
SNMP Community Name (public):
Disable Telnet Setup (N)
Disable TFTP Firmware Update (N)
Disable Port 77FEh (N)
Disable Web Server (N)
Enable Enhanced Password (N)

3.8.1 Disable SNMP

Note: This option does not appear with UDS-10-IAP.
This setting allows you to disable the SNMP protocol on the unit for security reasons.

3.8.2 SNMP Community Name

Note: This option does not appear with UDS-10-IAP.
This option allows you to change the SNMP Community Name on the unit. This allows for
ease of management, and possibly some security. If someone tries to violate security but
doesn't know what community to connect to, that person will be unable to get the SNMP
community information from the unit.
UDS-10 User Guide
(Not with IAP)
(Not with IAP)
Configure
3-25
