Table 11 - Modem Mode Commands - Lantronix Device Server UDS 10 User Manual

Configure

Table 11 - Modem Mode Commands

Modem Mode
Command
ATDTx.x.x.x,pppp or
ATDTx.x.x.x/pppp
ATDTx.x.x.x
ATD0.0.0.0
ATD
ATDx.x.x.x
ATH
ATS0=n
ATEn
ATVn
Note: These AT commands are only recognized as single commands like ATE0 or ATV1;
compound commands such as ATE0V1 are not recognized. All other AT commands with
Modem Mode set to full verbose acknowledge with an OK, but no action is taken.
3-20
Function
Makes a connection to an IP address (x.x.x.x) and a remote port
number (pppp).
Makes a connection to an IP address (x.x.x.x) and the remote port
number defined within the unit.
Forces the unit into monitor mode if a remote IP address and port
number are defined within the unit.
Forces the unit into monitor mode if a remote IP address and port
number are not defined within the unit.
Makes a connection to an IP address (x.x.x.x) and the remote port
number defined within the unit.
Hangs up the connection (Entered as +++ATH ).
Enables or disables connections from the network going to the serial
port.
n=0 disables the ability to make a connection from the network to
the serial port.
n=1-9 enables the ability to make a connection from the network
to the serial port.
n>1-9 is invalid.
Enables or disables character echo and responses.
n=0 disables character echo and responses.
n=1 enables character echo and responses.
Enables 1-character response or full verbose.
n=0 enables 1-character response.
n=1 enables full verbose.
UDS-10 User Guide
