Related Manuals for ORiNG IAP-420 Series
Summary of Contents for ORiNG IAP-420 Series
-
Page 2: Contact Information
(5 years for most products). ORing will repair or replace products found by ORing to be defective within this warranty period, with shipment expenses apportioned by ORing and the distributor. -
Page 3: Table Of Contents
System Info Settings ......................17 LAN Setting ......................... 18 Time Setting ......................... 20 5.4.3 Wireless Settings ..................... 21 Wireless Settings ........................21 Client Mode .......................... 28 Bridge Mode ......................... 30 Wireless Options ........................33 5.4.4 Advanced Settings ................... 35 ORing Industrial Networking Corp. - Page 4 Traffic/Port Status ......................... 41 System Log........................... 42 5.4.7 Administrator ....................42 Password ..........................42 Configuration ........................43 Firmware Upgrade ........................ 43 Load Factory Default ......................44 Restart ..........................44 Technical Specifications ................46 Compliance ....................48 ORing Industrial Networking Corp.
-
Page 5: Getting Started
Redundant power inputs: 12~48 VDC on terminal block Operating temperature: -10 to 60 Storage temperature: -40 to 85 Operating humidity: 5% to 95%, non-condensing Casing: IP-30 Dimensions (W x D x H): 41(W)x81(D)x95(H) mm ORing Industrial Networking Corp. -
Page 6: Hardware Overview
Ports Duplex: auto The ETH1 port of IAP-420+ is PoE-enabled ANT. 1 x reversed SMA connector for Wi-Fi antennal *Note: For PoE Ethernet switch options, please refer to information on the ORing IPS series. IAP-420+ IAP-420 ORing Industrial Networking Corp. -
Page 7: Front Panel Leds
Din-rail installation (blue box in the figure below). For more information on installation, please refer to 3.1 Din-rail Installation. 1. Wall-mount screw holes 2. Din-rail screw holes ORing Industrial Networking Corp. -
Page 8: Top Panel
IAP-420/420+ User Manual 2.4 Top Panel 1. Terminal block 2. Wall-mount screw holes ORing Industrial Networking Corp. -
Page 9: Hardware Installation
Step 1: Slant the device and screw the Din-rail kit onto the back of the device, right in the middle of the back panel. Step 2: Slide the device onto a DIN-rail from the Din-rail kit and make sure the device clicks into the rail firmly. ORing Industrial Networking Corp. -
Page 10: Wall Mounting
Step 2: Use the device, with wall mount plates attached, as a guide to mark the correct locations of the four screws. Step 3: Insert four screw heads through the large parts of the keyhole-shaped apertures, and then slide the device downwards. Tighten the four screws for added stability. ORing Industrial Networking Corp. -
Page 11: Wiring
Step 1: insert the negative/positive DC wires into the V-/V+ terminals, respectively. Step 2: to keep the DC wires from pulling loose, use a small flat-blade screwdriver to tighten the wire-clamp screws on the front of the terminal block connector. ORing Industrial Networking Corp. - Page 12 The rule of thumb is that wiring sharing similar electrical characteristics can be bundled together 7. You should separate input wiring from output wiring 8. It is advised to label the wiring to all devices in the system ORing Industrial Networking Corp.
-
Page 13: Ethernet Cables
PC and the device. The following table below shows the 10/100BASE-T(X) MDI and MDI-X port pin outs. 4.3 Wireless Antenna The device uses one reversed SMA connector for 2.4GHz antennas. You can also use external RF cables and antennas with the connectors. ORing Industrial Networking Corp. - Page 14 IAP-420/420+ User Manual ORing Industrial Networking Corp.
-
Page 15: Management
5.1 Open-Vision Configuration The device can be configured using ORing’s proprietary Windows utility Open-Vision. Follow the steps below to set up the device in Open-Vision. Step 1: Open the commander and click Discover, a list of AP devices will be shown. - Page 16 Step 3: Click on the icon and you will find the UPnP device in My Network Places. Step 4: Right click the UPnP device and choose Properties, the following picture will be shown. Step 5: Double click the device icon will lead you to the management web page. ORing Industrial Networking Corp.
-
Page 17: Web Browser Management
After you log in successfully, a Web interface will appear, as shown below. On the left hand side of the interface is a list of functions where you can configure the settings. The details of the configurations will be shown on the right screen. ORing Industrial Networking Corp. -
Page 18: Configuration
5.4.1 Overview System Info This page will show the basic information of the device based on the settings you input in Basic Settings/System Info Settings. The information includes model name, device name, location, description, and firmware version. ORing Industrial Networking Corp. -
Page 19: Lan Info
Wireless Settings. The information includes MAC address, SSID, peer AP SSID, encryption type, channel number, operation mode, and RF type. 5.4.2 Basic Setting System Info Settings This section allows you to input the basic information for the device. ORing Industrial Networking Corp. -
Page 20: Lan Setting
This page allows you to configure the IP settings of the LAN port for the device. To access the AP normally, a valid IP address of your LAN should be designated to the LAN interface. The default IP setting is DHCP server which will obtain an IP address automatically. ORing Industrial Networking Corp. - Page 21 You can choose to use HTTP or HTTPS protocols. The latter has a higher security level. Preferred DNS Input the IP address of the DNS server you prefer to use Secondary DNS Input the IP address of another DNS server ORing Industrial Networking Corp.
-
Page 22: Time Setting
Specify the scheduled time for synchronization Local Date Set a local date manually Local Time Set a local time manually Get Current Date & Click this button, you can set the time from browser. Time from Browser ORing Industrial Networking Corp. -
Page 23: Wireless Settings
In this mode, the AP functions as a wireless client to connect your wired devices to a wireless network. This mode provides no access point services but supports 802.1X. Bridge This mode provides static LAN-to-LAN bridging functionality. The static LAN-to-LAN bridging function is supported through Wireless Distribution System (WDS). ORing Industrial Networking Corp. - Page 24 You can choose the security type for your WLAN connection from the following options: Security Options None: no encryption WEP: WEP (Wired Equivalent Privacy) is a wireless security protocol for WLAN. WEP will encrypt data ORing Industrial Networking Corp.
- Page 25 AP. If select WEPAUTO, the clients do not have to use the same Open or Shared authentication. They can choose any one to authenticate. WEP Encryption You can select 64 Bit or 128 Bit. ORing Industrial Networking Corp.
- Page 26 Enter a pass phrase in this field. The value must be within 8 to Shared Key 64 characters When you set security type as WPA/WPA2 Enterprise, the following fields will appear to allow ORing Industrial Networking Corp.
- Page 27 Radius Port Enter the RADIUS port (default is 1812) Shared Secret Enter the RADIUS password or key When you set security type as 802.1x, the following fields will appear to allow you to configure individual settings. ORing Industrial Networking Corp.
- Page 28 When you configure the remote access server for RADIUS authentication, the credentials of the connection request are passed to the RADIUS server for authentication and authorization. If the request is both authenticated and authorized, the RADIUS server sends an accept ORing Industrial Networking Corp.
- Page 29 The principle of the Radius server is shown in the following pictures: AP-Client Mode This mode provides a one-to-many MAC address mapping mechanism such that multiple stations behind the AP can transparently connect to the other AP even if they don’t support WDS. ORing Industrial Networking Corp.
-
Page 30: Client Mode
Select the security type used by the client you want to connect Client Mode In this mode, the AP functions as a wireless client to connect your wired devices to a wireless network. This mode provides no access point services but supports 802.1X. ORing Industrial Networking Corp. - Page 31 Enter the SSID of the AP you want to connect as a client Peer AP BSSID Enter the BSSID (Wireless MAC address) to limit client target Site Scan Enables or disables slave mode Security Type Select the security type used by the client you want to connect ORing Industrial Networking Corp.
-
Page 32: Bridge Mode
MAC addresses of up to 64 wireless or 128 wired and wireless network devices, which are connected to their respective Ethernet ports to limit the amount of forwarded data. Only data destined for stations which are known to reside on the peer Ethernet link, multicast data ORing Industrial Networking Corp. - Page 33 In this mode, repeater is used to extend the range of the wireless infrastructure by forwarding traffic between associated wireless stations and another repeater or AP connected to the wired LAN. The peer WDS APs are based on the MAC addresses listed in Peer Mac Address. ORing Industrial Networking Corp.
- Page 34 IAP-420/420+ User Manual ORing Industrial Networking Corp.
-
Page 35: Wireless Options
The default value is 100, but 50 is recommended when reception is poor. DTIM Interval The default value is 1. This value, between 1 and 255 milliseconds, indicates the interval of the Delivery Traffic ORing Industrial Networking Corp. - Page 36 AP. Max Client Threshold This is the maximum number of clients for an AP. When the number of clients exceeds the value, the AP will reject the roaming connection. This value is only used on ORing Industrial Networking Corp.
-
Page 37: Advanced Settings
This page allows you to set up MAC filters to allow or deny wireless clients to connect to the AP. You can manually add a MAC address or select a MAC address from the Associated Clients list currently associated with the AP. ORing Industrial Networking Corp. -
Page 38: Misc. Settings
Select one of the options to allow or deny the MAC address in the list Associated Clients Shows the wireless MAC addresses associated with the device MAC Filter Table You can edit up to MAC addresses in these fields Misc. Settings ORing Industrial Networking Corp. -
Page 39: Event Warning Settings
You can choose the system to issue a notification when specific events occur by checking the box next to the event. This page shows the recorded events and setting changes of the AP. Rebooting the device will clear the list. ORing Industrial Networking Corp. -
Page 40: E-Mail
Enter the IP address of a remote server if you want the logs to be stored remotely. Leave it blank will disable remote syslog. Syslog Server Port Specifies the port to be logged remotely. Default port is 514. E-mail ORing Industrial Networking Corp. - Page 41 Enter a backup host to be used when the primary host is unavailable. Server Port Specifies the port where MTA can be contacted via SMTP server E-mail Enter the mail address that will receive notifications Address 1-4 ORing Industrial Networking Corp.
-
Page 42: Snmp
IAP-420/420+ User Manual SNMP Label Description SNMP Agent SNMP (Simple Network Management Protocol) Agent is a service ORing Industrial Networking Corp. -
Page 43: System Status
This page displays the network traffic statistics for both received and transmitted packets through the Ethernet port and wireless connections associated with the AP. Note that the traffic counter will reset when the device is rebooted. ORing Industrial Networking Corp. -
Page 44: System Log
You can click Refresh to renew the page or Clear to clear all or certain log entries. 5.4.7 Administrator Password This page allows you to change the username and password. You must type in the new password twice to confirm (the default username and password are admin). ORing Industrial Networking Corp. -
Page 45: Configuration
Upload. Restore Default Click to reset the device to the factory settings. The device will reboot Settings to validate the default settings. Firmware Upgrade ORing launches new firmware constantly to enhance performance and functions. To upgrade ORing Industrial Networking Corp. -
Page 46: Load Factory Default
IAP-420/420+ User Manual firmware, download new firmware from ORing’s website to your PC and install it via Web upgrade. Make sure the firmware file matches the model of your device. It will take several minutes to upload and update the firmware. After upgrade completes successfully, reboot the device. - Page 47 IAP-420/420+ User Manual ORing Industrial Networking Corp.
-
Page 48: Technical Specifications
IAP-420/420+ User Manual echnical Specifications ORing WLAN Access Point IAP-420 IAP-420+ Model Physical Ports 10/100 Base-T(X) Ports in RJ45 Auto MDI/MDIX Present at ETH Fully compliant with IEEE 802.3af Power Device specification PoE P.D. port Over load & short circuit protection Isolation Voltage: 1000 VDC min. - Page 49 5% to 95% Non-condensing Regulatory approvals FCC Part 15, CISPR (EN55022) class A EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11 Shock IEC60068-2-27 Free Fall IEC60068-2-32 Vibration IEC60068-2-6 Safety EN60950-1 Warranty 3 years ORing Industrial Networking Corp.
-
Page 50: Compliance
“Digital Apparatus,” ICES-003 of Industry Canada. Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe B prescrites dans la norme sur le matérial brouilleur: “Appareils Numériques,” NMB-003 édictée par l’Industrie. ORing Industrial Networking Corp. - Page 51 Avertissement d'exposition RF: L'équipement est conforme aux limites d'exposition aux RF établies pour un incontrô lés environnement. L'antenne (s) utilisée pour ce transmetteur ne doit pas être co-localisés ou fonctionner en conjonction avec toute autre antenne ou transmetteur. ORing Industrial Networking Corp.
