Industrial

Wireless Access Point

IAP-320 / 320+ User's Manual
Version 1.0
Jan, 2010.
ORing Industrial Networking Corp.
4F, NO.3, Lane235, Baociao Rd. Sindian City,
Taipei County 23145 Taiwan, R.O.C.
Tel: + 886 2 2918 3036
Fax: + 886 2 2918 3084
Website: www.oring-networking.com
E-mail:
support@oring-networking.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IAP-320 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ORiNG IAP-320

Summary of Contents for ORiNG IAP-320

  • Page 1: Wireless Access Point

    Industrial Wireless Access Point IAP-320 / 320+ User’s Manual Version 1.0 Jan, 2010. ORing Industrial Networking Corp. 4F, NO.3, Lane235, Baociao Rd. Sindian City, Taipei County 23145 Taiwan, R.O.C. Tel: + 886 2 2918 3036 Fax: + 886 2 2918 3084 Website: www.oring-networking.com...

  • Page 2: Table Of Contents

    Table of Content Getting to Know Your Access Point ............1 About the ORing Access Point ..................1 Software Features ......................1 Hardware Features ......................1 Hardware Installation ..................2 Installation AP on DIN-Rail ....................2 Wall Mounting Installation ....................3 Hardware Overview ..................
  • Page 3 5.5.2 Advanced Setting ......................29 Wireless ............................ 29 MAC Filter ..........................31 System Event ..........................32 Email Settings .......................... 33 SNMP Settings ......................... 34 Syslog Server Settings ......................34 5.5.3 System Tools ........................35 Administrator ........................... 35 Date & Time ..........................36 Configuration ...........................

  • Page 4: Getting To Know Your Access Point

    It can be configured to operate in AP/Bridge/Repeater/AP-Client/Client mode. You can configure IAP-320 / 320+ by Window Utility or WEB interfaces via LAN port or WLAN interface. IAP-320 / 320+ provide dual Ethernet ports in switch mode, so you can use Daisy Chain to reduce the usage of Ethernet switch ports.

  • Page 5: Hardware Installation

    IAP-320 / 320+ User’s Manual ardware Installation Installation AP on DIN-Rail Each AP has a DIN-Rail kit on rear panel. The DIN-Rail kit helps AP to fix on the DIN-Rail. It is easy to install the AP on the DIN-Rail: Step 1: Slant the AP and mount the metal spring to DIN-Rail.

  • Page 6: Wall Mounting Installation

    IAP-320 / 320+ User’s Manual Wall Mounting Installation Each AP has another installation method to fix the AP. A wall mount panel can be found in the package. The following steps show how to mount the AP on the wall: Step 1: Remove DIN-Rail kit.
  • Page 7 IAP-320 / 320+ User’s Manual The screws specification shows in the following two pictures. In order to prevent the AP from any damage, the screws should not larger than the size that used in IAP-320 / 320+. Pozidrive Step 3: Mount the combined AP on the wall.

  • Page 8: Hardware Overview

    IAP-320 / 320+ User’s Manual ardware Overview Front Panel The following table describes the labels that stick on the IAP-320 / 320+. Port Description 2 10/100Base-T(X) RJ-45 fast Ethernet ports support 10/100 RJ-45 fast Ethernet ports auto-negotiation. Default Setting : Speed: auto PoE P.D.
  • Page 9 4. LED for PWR2 and system status. When the PWR2 links, the green LED will be light 5. LED for Fault Relay. When the fault occurs, the amber LED will be light on. 6. 10/100Base-T(X) Ethernet ports. (IAP-320+ contains P.D. function of PoE) 7. LED for Ethernet ports status.

  • Page 10: Front Panel Leds

    IAP-320 / 320+ User’s Manual Front Panel LEDs Color Status Description Green On PoE power connected. Green blinking Device been located P.O.E. Green/Red Indicates an IP conflict, or (IAP-320+) Red blinking DHCP or BOOTP server did not respond properly Green On DC power 1 activated.

  • Page 11: Bottom Panel

    IAP-320 / 320+ User’s Manual Bottom Panel The bottom panel components of IAP-320 / 320+ are showed as below: 1. Terminal block includes: PWR1, PWR2 (12 ~ 48V DC) and Relay output (1A@24VDC). 2. Reset bottom. Push the bottom 3 seconds for reset; 5 seconds for factory default.

  • Page 12: Cables And Antenna

    Ethernet Cables The IAP-320 / 320+ WLAN AP have standard Ethernet ports. According to the link type, the AP use CAT 3, 4, 5,5e UTP cables to connect to any other network device (PCs, servers, switches, routers, or hubs). Please refer to the following table for cable specifications.

  • Page 13: Wireless Antenna

    Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair. Wireless Antenna A 2.4GHz antenna is used for IAP-320 / 320+ and connected with a reversed SMA connector. External antenna also can be applied with this connector.

  • Page 14: Management Interface

    Explore IAP-320 / 320+ 5.1.1 AP-Tool software Each model contains friendly software, AP-Tool, to explore IAP-320 / 320+ on local area network. Step 1: Open the AP tool and click “Refresh list”, the AP devices will show on the list.

  • Page 15: Upnp Equipment

    IAP-320 / 320+ User’s Manual UPnP Equipment Step 1: To check whether the UPnP UI of the computer is connected to the IAP-320 / 320+, go to Control Panel > Add or Remove Programs > Windows Components Wizard > Networking Servers > UPnP User Interface and pitch on the UPnP User Interface.
  • Page 16 IAP-320 / 320+ User’s Manual Step 3: Click the sign of the UPnP equipment, then you will find the UPnP equipment in the network neighborhood. Step 4: Right click the UPnP equipment to choose “Properties”, it will show as the following pictures: Step 5: Right click the UPnP equipment or double click the UPnP equipment to transfer;...

  • Page 17: Configuration By Web Browser

    IAP-320 / 320+ User’s Manual Configuration by Web Browser This section introduces the configuration by Web browser. About Web-Based Management An embedded HTML web site resides in flash memory in the system. It contains advanced management features and allows you to manage the AP from anywhere on the network through a standard web browser such as Microsoft Internet Explorer.

  • Page 18: Main Interface

    IAP-320 / 320+ User’s Manual Main Interface The Home screen will appear. Please click “Run Wizard” to go to the Home > Setup Wizard page to quick install the AP. Main interface 5.5.1 Basic Setting Setting Operation Mode Operation mode interface The following table describes the labels in this screen.

  • Page 19: Setting Wds (Bridge Mode)

    The static LAN-to-LAN bridging function is supported through Wireless Distribution System (WDS). In each mode, the IAP-320 / 320+ forwards packet between its Ethernet interface and wireless interface for wired hosts on the Ethernet side, and wireless hosts on the wireless side.
  • Page 20 IAP-320 / 320+ User’s Manual Point-to-Multipoint WDS Link Point-to-Point WDS Link The following table describes the labels in this screen. Label Description WDS Mode This mode provides Static LAN-to-LAN Bridging functionality. The static LAN-to-LAN bridging function is supported through Wireless Distribution System (WDS).
  • Page 21 IAP-320 / 320+ User’s Manual Peer MAC Address Set the Mac address(es) of other access point(s). Simultaneity, choose on “Enable”. First of all, if APs link with WDS mode, it should obey the following rules: 1. LAN IP Address should set different IP in the same network.
  • Page 22 IAP-320 / 320+ User’s Manual WDS –Bridge Mode Same as Restrict mode in functionality and also one WDS link side can not set Peer Mac Address 1-4. The working principle of Bridge Mode as follows: In the figure, the AP behaves as a standard bridge that forwards traffic between WDS links (links that connect to other AP/wireless bridges) and an Ethernet port.
  • Page 23 IAP-320 / 320+ User’s Manual WDS –Repeater Mode Same as Restrict mode in functionality and also one WDS link side can not set Peer Mac Address 1-4. The working principle of Repeater Mode as follows: In the figure, Repeater is used to extend the range of the wireless infrastructure by forwarding traffic between associated wireless stations and another repeater or AP connected to the wired LAN.

  • Page 24: Setting Wireless

    IAP-320 / 320+ User’s Manual Setting Wireless The following table describes the labels in this screen. Label Description Service Set Identifier Default is the default setting. The SSID is a unique name that identifies a network. All devices on the...
  • Page 25 IAP-320 / 320+ User’s Manual Security Type – None No security protection on your wireless LAN access. Security Type – WEP Security Type: Select WEP WEP Encryption: Select 64 Bit or 128 Bit WEP encryption. Key Type: Select ASCII or Hex key type.
  • Page 26 IAP-320 / 320+ User’s Manual Security Type – WPA-PSK/WPA2-PSK 1. Security Type: Select WPA-PSK/WPA2-PSK. 2. Encryption Type: Select TKIP or AES encryption. 3. Share Key: Enter your password. The password can be between 8 and 64 characters. Security Type – WPA /WPA2 1.
  • Page 27 IAP-320 / 320+ User’s Manual Security Type – 802.1x 1. Security Type: Select 802.1x 2. WEP Encryption: Select 64 Bit or 128 Bit WEP encryption. 3. Key Type: Select ASCII or Hex key type. 4. Default Key Index: Select one of the keys to be the active key.
  • Page 28 IAP-320 / 320+ User’s Manual RADIUS (Remote Authentication Dial-in User Service) is the industrial standard agreement, and it is used to provide an identify verification. The Radius customer (is usually a dial-in server, VPN server or wireless point) send your proof and the conjunction parameter to the Radius server by Radius news.

  • Page 29: Ap-Client/Client

    IAP-320 / 320+ User’s Manual AP-Client/Client The Basic setting—>AP-Client/Client page is mainly set the client which through the SSID and Security to connect to other AP. In this mode, the Security Type should be the same with the AP Server.

  • Page 30: Lan Setting

    Select this option if you would like to have an IP address Obtain an IP address automatically automatically assigned to the IAP-320 / 320+ by DHCP server in your network Use the following IP Select this option if you are manually assigning an IP address.

  • Page 31: Setting Dhcp Server

    IAP-320 / 320+ User’s Manual devices on the network must have the same subnet mask to communicate on the network. Default Gateway: Enter the IP address of the router in your network. Obtain DNS server This option is selected by DHCP server.

  • Page 32: Advanced Setting

    IP is idle. DHCP Clients List List the devices on your network that are receiving dynamic IP addresses from the IAP-320 / 320+. 5.5.2 Advanced Setting Wireless The following table describes the labels in this screen.
  • Page 33 IAP-320 / 320+ User’s Manual multicast messages. When the AP has buffered broadcast or multicast messages for associated clients, it sends the next DTIM with a DTIM Interval value. Its clients hear the beacons and awaken to receive the broadcast and multicast messages.

  • Page 34: Mac Filter

    Use Advanced Setting > MAC Filters to allow or deny wireless clients, by their MAC addresses, from accessing the IAP-320 / 320+. You can manually add a MAC address or select the MAC address from Connected Clients that are currently connected to the...

  • Page 35: System Event

    IAP-320 / 320+ User’s Manual The following table describes the labels in this screen. Label Description MAC Filter Enable or disable the function of MAC filter. MAC address allowed or denied option is selected by you. This list will display the MAC addresses that are in the selected MAC Filter List filter.

  • Page 36: Email Settings

    IAP-320 / 320+ User’s Manual System events record the activities of the AP system. When the setting changes or action performs, the event will be sent to administrator by email. A trap will also be sent to SNMP server. The Syslog will record the event locally and may send the log remotely to a Syslog server.

  • Page 37: Snmp Settings

    IAP-320 / 320+ User’s Manual Server Port Specify the port where MTA can be contacted via SMTP server. E-mail Address 1-4 Inputs specify the destination mail address. SNMP Settings The following table describes the labels in this screen. Label Description...

  • Page 38: System Tools

    IAP-320 / 320+ User’s Manual The following table describes the labels in this screen. Label Description Syslog Server IP Not only the syslog keeps the logs locally, it can also log to remote server. Specify the IP of remote server. Leave it blank to disable logging remotely.

  • Page 39: Date & Time

    IAP-320 / 320+ User’s Manual '0-9', 'a-z', 'A-Z' and must be between 1 to 15 characters in length. This field can not accept null input. New Password Enter a new login password. Acceptable inputs of this field contains '0-9', 'a-z', 'A-Z' and must be between 0 to 15 characters in length.
  • Page 40 IAP-320 / 320+ User’s Manual The following table describes the labels in this screen. Label Description Local Date Set local date manually. Local Time Set local time manually. Time Zone Select the time zone manually Get Current Date & Click this button; you can set the time from browser.

  • Page 41: Configuration

    Click Upload when you have selected the file to be loaded back onto the AP. Restore Default You may also reset the IAP-320 / 320+ back to factory settings by Settings clicking on Restore Default Settings. Make sure to save the unit’s settings before clicking on this button.

  • Page 42: Miscellaneous

    IAP-320 / 320+ User’s Manual minutes to upload and upgrade the firmware. After the upgrade is done successfully, the access point will reboot and get revalidated. Notice: DO NOT POWER OFF THE AP OR PRESS THE RESET BUTTON WHILE THE FIRMWARE IS BEING UPGRADED.

  • Page 43: System Status

    IAP-320 / 320+ User’s Manual 5.5.4 System Status System Info This page displays the current information for the IAP-320 / 320+. It will display model name, as well as firmware version, Ethernet, Wireless info and device time. System Log The system log tracks the important events and setting changes of the AP. If the AP is rebooted, the logs are automatically cleared.

  • Page 44: Traffic Statistics

    IAP-320 / 320+ User’s Manual Click the button 'Refresh' to refresh the page; Click the button 'Clear' to clear log entries. Traffic Statistics This page displays the network traffic statistics for both received and transmitted packets through the Ethernet port and wireless connections associated with the AP.

  • Page 45: Online Help

    IAP-320 / 320+ User’s Manual 5.5.5 Online Help Click on any item in the Online Help screen for more information. ORing Industrial Networking Corp.

  • Page 46: Technical Specifications

    IAP-320 / 320+ User’s Manual echnical pecifications LAN Interface RJ45 Ports 2 x 10/100Base-T(X), Auto MDI/MDI-X PoE P.D. (Power Device) Present at ETH2 of IAP-320+ ETH2 act as Power Device (IEEE802.3af): IEEE 802.3af compliant input interface Power consumption: 8Watts max.
  • Page 47 IAP-320 / 320+ User’s Manual LED Indicators PWR 1(2) (PoE, IAP-320+) / Ready: 1) Red On: Power is on and booting up. 2) Green On: Power is on and functioning normally. ETH1 (2) Link / ACT: Orange ON/Blinking: 10 Mbps Ethernet...

  • Page 48: Appendixa

    1. The location of the License should configure right during the process of the installation. 2. After the installation, click into MIB Compile to add the MIB files(for example, the Oring 802.11a/b/g and no PoE FW), and save the configuration.
  • Page 49 IAP-320 / 320+ User’s Manual 3. Open MIB Brower and select the list of MIB, then select the ORING-ABG-2Port-AP-MIB which in the MIB Modules to add in the Loaded MIB modules. 4. Click into Query list in the MIB Brower, and input the IP address of the AP in the Remote SNMP agent click “Apply”, there is an alarm box which let you enter the right...
  • Page 50 IAP-320 / 320+ User’s Manual 5. After all the settings, you can see the information about the Oring AP in the MIB Tree. ORing Industrial Networking Corp.
  • Page 51 IAP-320 / 320+ User’s Manual Step 3, Be familiar with SNMP information 1. The apNotifs list will show the trap box. To modify password as an example select the SNMP Trap option in the Advanced Setting System Event page modify the password in the page of Administrator it will be have trap box in the SNMP.
  • Page 52 IAP-320 / 320+ User’s Manual 4. Also have the relevant information, you can right-click “Properties” to view a specific property features. ORing Industrial Networking Corp.
