Operating Controls

Terminal is used to connect Va.c. power to the
01
control board.
10 Amp fuse to protect the electronic circuit
02
board.
SBY-3 Battery Charger connection to attach
03
a Battery Back Up kit.
24Vd.c. Motor Connection.
04
OPERATE button (Blue) is used during
05
installation to test the open, stop and close
cycles for the opener. The opener has to be
initialised by the LIMIT SET button to make the
OPERATE button operable.
button also can be used in lieu of a transmitter
to activate the opener.
PLUS (+) button (Green) is used during
06
installation to set the open limit position.
Pressing and holding this button will move the
door in the open direction. Movement stops
when the button is released.
NOTE: The safety obstruction system is
inoperable whenever the PLUS (+) button is
used to move the door.
PROG INPUT is used to connect the PG-3
07
Universal Handheld Programmer to edit control
and receiver functions.
OPEN LIMIT LED (Green) is used during
08
installation to help set the open limit position. It
also illuminates and fl ashes as the door opens,
and remains on when the open limit position
has been reached.
FORCE MARGIN
09
obstruction force margin is set automatically
during installation. The margin can be adjusted
manually using the FORCE MARGIN SET
button (White). Holding the FORCE MARGIN
SET button and pressing PLUS (+) or MINUS (-)
buttons will increase or decrease the amount of
force. The FORCE MARGIN SET button should
only be used if environmental factors, such as
high winds, affect the door's operation.
CLOSE LIMIT LED (Red) is used during
10
installation to set the close limit position. It also
illuminates and fl ashes as the door closes, and
remains on when the close limit position has
been reached.
SecuraLift ® Trio Overhead Garage Door Opener
8
The OPERATE
SET button. The
Owner Installation Instructions
MINUS (-) button (Red) is used during installation to set
11
the close limit position. Pressing and holding this button
will move the door in the close direction. Movement
stops when the button is released. This button is also
used for storing or erasing the transmitter button you
wish to use to command the door to open, stop or
close.
NOTE: The safety obstruction system is inoperable
whenever the MINUS (-) button is used to move the
door.
CODE SET LED (Red) fl ashes when a transmitter button
12
is stored.
LIMIT SET button (Blue) is used during installation,
13
together with the PLUS (+) and MINUS (-) buttons, to set
the door limit positions. The LIMIT SET button is also
used to re-initialise the opener.
SERVICE LED (Yellow) indicates when the opener
14
requires service or repairs.
Courtesy Light LED Module connects the 24V LED
15
lighting modules.
Terminal Block:
16
30V PWR - Used to power devices such as P.E.
Beams and external receiver (100
milliamp max).
P.E - Input to connect to P.E. Beams.
P.E 0V - 0 volt connection for P.E. Beams.
GND - Common -ve ground for accessories
OPERATE - Used for the connection of a wired
switch (momentary contact). This
switch can then be used to open,
stop or close the door. Install the
wall switch in a location where the
switch is out of reach of children and
the garage door is visible.
AUX OUT - This function allows the opener to
operate other devices such as
external lights, or an alarm system.
