AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD
S
L
ECURA
IFT
GARAGE DOOR OPENER
Warning: Failure to comply with the
Installation instructions and the
OWNERS COPY
Safety warnings may result in
Serious Personal Injury and/or
Installation Instructions
Property Damage and/or Remote
Control Opener Damage.
And Owners Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SECURALIFT and is the answer not in the manual?

Questions and answers

Roger Hinves
June 4, 2025

How do I add (program) a remote controller.

0

Subscribe to Our Youtube Channel

Related Manuals for Automatic Technology SECURALIFT

Summary of Contents for Automatic Technology SECURALIFT

  • Page 1 AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD ECURA GARAGE DOOR OPENER Warning: Failure to comply with the Installation instructions and the OWNERS COPY Safety warnings may result in Serious Personal Injury and/or Installation Instructions Property Damage and/or Remote Control Opener Damage. And Owners Manual...

  • Page 2: Table Of Contents

    Contents Page IMPORTANT SAFETY WARNINGS PRODUCT FEATURES OPERATING CONTROLS TUBE/PIPE ASSEMBLY 6 & 7 DETERMINE WHICH TYPE OF GARAGE DOOR MOUNTING OPENER– SECTION DOOR/ONE PIECE DOOR WITH TRACK MOUNTING OPENER– ONE PIECE DOOR WITH OUT TRACK 9 & 10 MOUNTING DOOR BRACKET & ARMS SETTING UP OF LIMITS / SETTING OBSTRUCTION FORCES 11 &...
  • Page 3 Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties Statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia SecruaLift Opener and Automatic Tech- nology Australia Pty Ltd hereby further expressly excludes all or any liability for any injury damage, cost, expense or claim whatsoever suffered by any person as a result whether directly or indirectly from failure to install the Automatic Technology Australia Door Opener in accordance with these installation instructions.
  • Page 4 F E AT U R E S Your Securalift Automatic Garage Up to 27 different codes can be OPEN AND CLOSE DRIVE Door Opener has many features stored in the Openers memory. BUTTONS which you will appreciate. The To store any code simply press and...

  • Page 5: Operating Controls

    O P E R AT I N G C O N T R O L S s e e F i g . 1 5 1. LIGHT CODE button (White) CLOSE LIMIT ADJUST 15. P.E. Input is for connection of is used for storing or erasing the SCREW (Red) is used to fine adjust Photo Electric Beams (optional...

  • Page 6: Tube/Pipe Assembly

    LIMITS ARE PRE-SET IN FACTORY PLEASE READ THIS INSTRUCTION MANUAL BEFORE ATTEMPTING TO INSTALL AND USE THE OPERATOR. FAILURE TO COMPLY WITH THE INSTALLATION INSTRUCTIONS MAY RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE. T U B E / P I P E A S S E M B LY FIG.

  • Page 7: Determine Which Type Of Garage Door

    FIG. 4 STEP 4 Remove locating screwdriver from trolley. Disengage trolley from chain index by swinging lever downwards (FIG. 4), then slide trolley away from chain index along pipe track. Loosen locking nuts on chain index screws. To tighten chain, turn chain index in anti-clockwise direction, looking from support pipe assembly to drive unit.
  • Page 8 Mounting Operator – Sectional door/one piece door with track STEP 6 The intersection of line 21.5mm from door centre and line 60mm above highest point of travel are centre points, where holes for mounting of wall bracket should be drilled. (FIG. 6) If wall bracket is mounted onto concrete or brick wall, use 8mm or 5/6 loxins.

  • Page 9: Mounting Opener- One Piece Door Without Track

    MOUNTING OPENER– ONE PIECE DOOR WITHOUT TRACK STEP 9 CENTER OF DOOR Determine the centre of the door and mark this location on the wall above and on top of the door. Then draw two (2) lines 21.5mm on each side of the door.

  • Page 10: Mounting Door Bracket & Arms

    STEP 12 Mark a line through the centre of the wall bracket onto the header wall (above the door). Drill holes at intersection of the above line and lines 21.5mm from the centre line of the door. ( Step 9) If wall bracket is mounted onto concrete or brick wall, use M8 or 5/6 loxins.

  • Page 11: Setting Up Of Limits / Setting Obstruction Forces 11

    The safety obstruction force is calculated automati- When the doors desirable open position is reached, cally and set in the memory of the Securalift. This release button and door will stop. Turn open limit applies to both the Open Force and Close Force..
  • Page 12 16.1 TO INITIALISE OBSTRUCTION FORCE 1. Press and hold down the close button 3 (FIG. 16), to move the door to the fully closed position. Check that the RED LED 4 is steady ON, to confirm the door is set on the closed limit position 2.

  • Page 13: Storing Additional Transmitters

    16.5 CLOSE SAFETY OBSTRUCTION TEST. The door now must be tested for response to an obstruction while it is opening and closing. Press the yellow button with the door in the open position, the door should start closing. When the door reaches half the closing distance hold the bottom of the door with your hands.
  • Page 14 STEP 17.3 STORING TRANSMITTER CODE TO STEP 19 SETTING OF COURTESY LIGHT OPERATE THE COURTESY LIGHT TIME The preset courtesy light time on the Door Opener is The Transmitter can be programmed to operate the 3 minutes. This time can be changed as below. Courtesy Light on the Door Opener.

  • Page 15: Setting Auto Close Mode

    STEP 20. FITTING OF SAFETY PHOTO ELECTRIC BEAM (OPTIONAL Locate the Photo Electric Beam (P.E.) normally closed contact type in a strategic location within doorway. Re- move shunt from P.E connector (FIG. 22a) and connect the plug from the P.E. wiring harness to P.E. connector 15 (FIG.
  • Page 16 PARTS LIST...

  • Page 17: Door Status Indicators

    DOOR STATUS INDICATORS DOOR OPENER STATE OPEN LED CLOSE SERVICE COURTESY BEEPER GREEN LIGHT YELLOW OPEN CLOSE OPENING Flashing CLOSING Flashing DOOR TRAVEL STOPPED Flashing Flashing DOOR OBSTRUCTED WHEN OPENING Flashing Beeps on and off DOOR OBSTRUCTED WHEN Flashing Beeps on and off CLOSING DOOR OVERLOADED Flashes ten times...
  • Page 18 FA U LT S A N D R E M E D I E S SYMPTOMS POSSIBLE CAUSES REMEDY * Door will not operate *Main power not turned on *Turn on *Door is obstructed *Remove obstruction *Door is locked or motor jammed *Unlock door and Inspect door and re-move jam *Door will not reverse when obstructed...

  • Page 19: Warranty

    * * WA R R A N T Y A N D E X C L U S I O N O F L I A B I L I T Y * * Subject to all of the matter set out below, Automatic Technology Australia Pty Ltd (“ATA”) WARRANTS for twenty four months from the date of purchase (specified in the receipt sales docket) that the Garage Door Opener System contained in the accompa- nying packaging (the “Product”) is free of any defects in material and workmanship rendering it unmerchantable.
