SecuraLift
Trio
®
DC Overhead Garage Door Opener
INSTALLATION INSTRUCTIONS | OWNER'S COPY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SecuraLift Trio and is the answer not in the manual?

Questions and answers

Summary of Contents for Automatic Technology SecuraLift Trio

  • Page 1 SecuraLift Trio ® DC Overhead Garage Door Opener INSTALLATION INSTRUCTIONS | OWNER’S COPY...
  • Page 2 Please save these instructions for future reference. Automatic Technology (Australia) Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology (Australia) Pty Ltd Garage Door Opener.
  • Page 3: Table Of Contents

    SecuraLift ® Trio Overhead Garage Door Opener Important Safety Instructions Features Operating Controls Kit Contents Installation C-Rail Assembly Determine Door Type Mounting on a Track Type Door Mounting on a Non-Track Type Door 16 Mounting Door Bracket & Arms Setting Travel Limits Testing Safety Obstruction Force Coding Transmitters Door...
  • Page 4: Important Safety Instructions

    In most countries P.E. Beams are mandatory on all automated garage doors. For a small ® additional outlay Automatic Technology recommends that P.E. Beams be installed with the SecuraLift Trio Overhead Garage Door Opener. DO NOT operate the SecuraLift® Trio Overhead Garage Door Opener unless the garage door is in full view and free from objects such as cars and children/people.
  • Page 5 Important Safety Instructions The garage door must be well balanced. Sticking or binding doors must be repaired by a qualifi ed garage door installer prior to installation of the SecuraLift® Trio Overhead Garage Door Opener. Frequently examine the installation, in particular cables, springs and mountings for signs of wear, damage or imbalance.
  • Page 6: Features

    Features Thank you for purchasing the SecuraLift® Trio Overhead Garage Door Opener. Designed to suit sectional, overhead and one piece tilt up doors, the components and materials used ensure this opener will provide years of smart, simple and secure operation. Listed below are just some of the many world leading features: Operation To open or close the door simply press a button on a TrioCode™...
  • Page 7 LED Courtesy Light The SecuraLift® Trio Overhead Garage Door Opener’s courtesy light illuminates automatically whenever the door is activated. The light can also be switched on and off without operating the door by pressing the button on any transmitter which has been coded to operate the light.
  • Page 8: Operating Controls

    Operating Controls Terminal is used to connect Va.c. power to the MINUS (-) button (Red) is used during installation to set control board. the close limit position. Pressing and holding this button will move the door in the close direction. Movement 10 Amp fuse to protect the electronic circuit stops when the button is released.
  • Page 9 Operating Controls SecuraLift ® Trio Overhead Garage Door Opener Owner Installation Instructions...
  • Page 10: Kit Contents

    Kit Contents Drive Unit 1 x SecuraLift® Trio drive unit (Fig. 01) 1 x Transmitter pack (Fig. 01) (Pack includes two keyring transmitters and batteries) 1 x Wall mount transmitter with battery (Fig. 01) 2 x Door attachment arms (Fig. 01) 1 x Accessory and hardware pack (Fig.
  • Page 11 Kit Contents Three Piece Knockdown Track With Pre-Assembled Chain IMPORTANT NOTE: If a modifi cation to the length of the track is required, the adjustment must be made from the drive unit end only. fi g Three Piece Knockdown Track With Pre-Assembled Timing Belt IMPORTANT NOTE: If a modifi...
  • Page 12: Fi G

    Knockdown C-Rail Assembly Start Swing Swing and straighten 4 Cut cable tie Slide sleeve 5 Swing fi g Slide sleeve Swing and straighten Turn tracks around 9 Tension 1/2” hex bolt Screws Screws To adjust the chain/belt tension, move the shuttle to middle of track, then using a spring scale measure the force required to pull the shuttle (The recommended pull force is 8kg (80N)).
  • Page 13: C-Rail Assembly

    C-Rail Assembly Step 2 - Attach Manual Disengage Cord If not already disengaged, fl ick the yellow clutch lever up so it sits perpedicular to the rail. Thread the loose end of the cord through the hole in the yellow clutch lever (Fig. 07). Thread the cord down to red toggle and knot through the spare hole.
  • Page 14: Determine The Door Type

    Determine the Door Type Step 4 Proceed from Step 5 Determine which type of garage door you have as illustrated (Fig. 10 - 12). For a sectional (panel) door on tracks (Fig. 10) proceed with the installation from Step 5. Track fi...
  • Page 15: Mounting On A Track Type Door

    Mounting on a Track Type Door WARNING: Make sure concrete, brick wall or timber lintels are solid and sound so as to form a Level secure mounting platform. The opener must be securely Level fastened to structural supports otherwise serious Track personal injury and/or property damage may ensue.
  • Page 16: Mounting On A Non-Track Type Door

    Mounting on a Non-Track Type Door WARNING: Make sure concrete, brick wall or Centre of door timber lintels are solid and sound so as to form a secure mounting platform. The opener must be securely fastened to structural supports otherwise serious personal injury and/or property damage may ensue.
  • Page 17: Mounting Door Bracket & Arms

    Mounting Door Bracket and Arms Step 12.1 - Alternative Mounting Option Drill hole at centre of The opener can be fastened to the roof by driving a bolt track (recommended bolt through the C-Rail into a structural timber support. The size M6 or M8) bolt head’s height must not exceed 6mm (Fig.
  • Page 18: Setting Travel Limits

    Setting Travel Limits IMPORTANT NOTE: The OPERATE button will not function until the open and close limit positions are set. NOTE: The door and shuttle must be engaged into the chain index. The door should be open approximately half way. fi...
  • Page 19: Testing Safety Obstruction Force

    Testing Safety Obstruction Force CAUTION: Take care when testing the safety obstruction force. Failure to do so can result in serious personal injury and/or property damage. 16.1 Test the Close Cycle Press the OPERATE button to open the door (Fig. 28).
  • Page 20: Coding Transmitters

    Coding Transmitters Step 17.1 - Storing the Transmitter Code The opener can only operate from transmitters that have been programmed into its receiver. The receiver needs to learn the codes of any transmitters to be used with the opener. Up to fourteen (14) codes can be stored in the receiver’s memory.
  • Page 21: Vacation Mode

    Coding Transmitters Step 17.3 - Setting the Transmitter to Operate Vacation Mode The opener can be programmed into a “Vacation Mode” where the opener will not respond to any transmitter except one pre-programmed unit. Press CODE SET Press CODE SET button three times. The CODE SET button three times fi...
  • Page 22: Pet (Pedestrian) Mode

    Coding Transmitters Step 17.5 - Setting the Transmitter to Operate Pet (Pedestrian) Mode The opener can be programmed into a “Pet Mode” where the door opens partially to allow pets to enter/exit the garage: Press CODE SET Press the CODE SET button fi ve times, the CODE button fi...
  • Page 23: Battery Back Up Installation

    Battery Back Up Installation fi g Battery Back Up (optional) Testing Battery Back Up The opener has provision for a Battery Back Up kit to Press either the OPERATE button or transmitter allow continued door operation without mains power. to activate the opener. Whilst the door is in motion disconnect mains power - the opener should continue to Installation...
  • Page 24: Accessories

    Accessories P.E. Beams For ADDITIONAL PROTECTION Automatic Technology STRONGLY recommend the fi tting of a P.E. Beams. In most countries P.E. Beams are mandatory on all garage doors fi tted with automatic openers. For a small additional outlay, Automatic Technology recommends that P.E.
  • Page 25: Remote Aerial

    Accessories Terminal Block A variety of wired accessory items can be connected to the terminal block such as P.E. Beams, electric key switch, door status indicators and more (Fig. 41). 30V PWR The terminal block also features and auxiliary output for controlling other devices from your transmitter.
  • Page 26: Troubleshooting Guide

    It is possible that these devices could cause a degree of interference such as to greatly reduce the range of the transmitter. In such an instance please contact your Automatic Technology dealer for an alternative frequency replacement kit. As this is not a warrantable situation but an environmental issue charges may apply for the changeover.
  • Page 27: Default Settings & Specifi Cations

    Default Settings and Specifi cations Factory default settings Default Step Minimum Maximum Maximum opener run time 30 seconds Courtesy light time 4 minutes (approx.) Obstruction force margin Auto-Close time 30 seconds Technical specifi cations Power supply 230V - 240Va.c. 50Hz Transformer rating 24Vd.c.
  • Page 28: Parameters

    Parameters DOOR STATUS INDICATORS Door opener state OPEN LED (green) CLOSE LED (red) Beeper Open Close Opening Flashing Closing Flashing Door travel stopped Flashing Flashing Door obstructed when opening Flashing Door obstructed when closing Flashing Beeps while door is moving Opener overloaded Alternating fl...
  • Page 29 Parameters BUTTON FUNCTIONS Button Function OPERATE Opens/stops/closes the door CODE SET Codes a transmitter button for operate function FORCE MARGIN SET & PLUS (+) Increases the obstruction force margin setting FORCE MARGIN SET & MINUS (-) Decreases the obstruction force margin setting FORCE MARGIN SET (then) LIMIT Reloads the factory set default obstruction force margin setting LIMIT SET (for 6 seconds)
  • Page 30: Maintenance

    Maintenance Maintenance Yearly The SERVICE LED will indicate the requirement for Automatic Technology suggests you contact your installer a service and/or adjustment. To reset the SERVICE to perform an annual door service. LED when the door is serviced, reprogram the Door Travel Limits and the Door Travel Force –...
  • Page 31 Maintenance Service Record Record any maintenance in the following table to assist in any warranty service. Date Service by Signature Invoice No. Amount SecuraLift ® Trio Overhead Garage Door Opener Owner Installation Instructions...
  • Page 32: Parts List

    Spare Parts List SecuraLift ® Trio Overhead Garage Door Opener Owner Installation Instructions...
  • Page 33 Spare Parts List SecuraLift ® Trio Overhead Garage Door Opener Owner Installation Instructions...
  • Page 34: Warranty

    Trade Practices Act 1974 (Cth). 2. Subject to all of the matters set out below, Automatic Technology Australia Pty Ltd (“ATA”) warrants: (a) swing and sliding gate opener drive units for twelve (12) months or 2500 cycles, whichever occurs fi rst;...
  • Page 35 SecuraLift ® Trio Overhead Garage Door Opener Owner Installation Instructions...
  • Page 36 © June 2007 Automatic Technology (Australia) Pty Ltd. All rights reserved. TrioCode™ and SecuraLift® Trio are trademarks of Automatic Technology (Australia) Pty Ltd. No part of this document may be reproduced without prior permission. In an ongoing commitment to product quality we reserve the right to change specifi cation without notice. E&OE.
