Coding Transmitters
fi g 34
fi g 35
fi g 36
SecuraLift ® Trio Overhead Garage Door Opener
22
Step 17.5 - Setting the Transmitter to Operate

Pet (Pedestrian) Mode

The opener can be programmed into a "Pet Mode"
where the door opens partially to allow pets to enter/exit
the garage:
Press CODE SET
a. Press the CODE SET button fi ve times, the CODE
button fi ve times
SET LED will illuminate and the courtesy light will
fl ash quickly (twice per second) to indicate learning
mode for Pet Mode is active. (Fig. 34)
b. Choose a transmitter button not already coded into
Select one of the
four buttons (not yet
the receiver. Press this button and the CODE SET
programmed) you wish
LED will begin to fl ash.
to use to control the
c. Press the same transmitter button again. The CODE
door for pet position
SET LED will illuminate for one second and then go
out, and the courtesy light will also switch off. This
indicates the code has been stored. This indicates
the code has been stored (Fig. 34).
Step 17.6 - To Erase Programmed Codes
If the CODE SET button is pressed and held for 6 seconds
the CODE SET LED will blink rapidly for one second to
indicate that all programmed codes have been erased.
(Fig. 35)
Step 17.7 - Installation of the Wall Mounted
Transmitter
a. Mount the transmitter in a convenient location, yet
out of reach of children and at least 1.5m off the
ground (Fig. 36).
b. Make sure the door is visible from this location.
c. To set the transmitter codes refer to Steps 17.1 to
17.5.
