Konica Minolta BIZHUB C20 User Manual page 12

Cleaning the Media Feed Rollers (Manual Feed Tray) 235
Cleaning the Media Feed Rollers (Tray 2/3) 237
Cleaning the Media Transfer Rollers for Tray 3 238
Cleaning the Media Feed Rollers for the ADF 239
Cleaning the Media Feed Rollers for the Duplex 240
Laser Lens
11 Troubleshooting ........................................................................................... 243
Introduction 244
Printing a Configuration Page 245
Unlocking the Scanner 246
Preventing Media Misfeeds 247
Understanding the Media Path 248
Clearing Media Misfeeds
Media Misfeed Messages and Clearing Procedures
Clearing a Media Misfeed from Tray 1 (Manual Feed Tray) and Transfer
Roller 250
Clearing a Media Misfeed in Tray 2 253
Clearing a Media Misfeed in Tray 3 256
Clearing a Media Misfeed from the ADF 259
Clearing a Media Misfeed from the Duplex 261
Clearing a Media Misfeed from the Fuser Unit 262
Clearing a Media Misfeed from the Switchback
Clearing a Media Misfeed from the Horizontal Transport Area
Solving Problems with Media Misfeeds 270
Solving Other Problems 273
Solving Problems with Printing Quality 281
Status, Error, and Service Messages 287
Status Messages
Error Messages
Service Messages
12 Installing Accessories .................................................................................. 299
Introduction 300
Antistatic Protection 301
Dual In-Line Memory Module (DIMM) 302
Installing a DIMM 302
Hard Disk Kit 305
Installing the Hard Disk kit 305
CompactFlash 309
Installing the CF adapter and CompactFlash card 309
Tray 3 (Lower Feeder Unit) 313
Kit Contents
Installing Tray 3
vi
241
248
287
288
297
313
314
249
266
268
Contents
