GRAPHTEC CS400 User Manual page 55

(1) Select Color Correction on the Scanner menu.
(2) Click the Scan button.
(3) The following message is displayed. Insert the color correction sheet in the scanner.
Position the color correction sheet so that the red bar in the center of the sheet is
centered in the scanner (but with the printed side down).
(4) Click the OK button to start scanning.
The scanned data is displayed when scanning is complete. Colors may differ slightly
for individual sensors, but this does not indicate a defect.
(5) When the data is displayed, click the Get button.
(6) Click in the center of the color tile indicated by the numbers 1 to 6, in ascending order.
For numbers 1 to 5, click the center of the upper left tile; for number 6, click in the center
of the bottom right tile. Align the cursor crosshairs with the printed lines at the sides
of the tile.
CS400/300
Cursor lines (red)
Align with the printed lines, then click.
5. DAILY MAINTENANCE
5 – 11
