(5) Attach the basket to the stand
Position frames 1 and 2 so that they rest on screws A and are hooked onto screws
B in order to attach the basket.
Frame 1
Screw A
Screw B
Screw A
(6) Attach frame 3 to screws B below screws A and stretch out the basket cloth.
Screw B
Screw A
(7) Always ensure that you remove the cushion material that is included below the document
hold-down unit before using the product. (Refer to Section 5.1, "Opening and Closing
the Top Cover".)
CS400/300
Basket
Frame 3
2. PREPARATION
Screw A
Screw B
Frame 2
Screw A
Screw B
Screw A
2 – 3
