Neckrest - Invacare rea Azalea Assist User Manual

1.
B
A
2.
C
D
28

NECkREST

1. To adjust the height of the neckrest, first loosen
the screw (B) in the stop block, then loosen the
handwheel (A). Adjust the neckrest to the desired
position and re-tighten the handwheel (A).
Now slide the stop block down to the top of the
neckrest attachment and tighten the screw (B).
It is now posible to remove the neckrest and
reinsert it again in the desired position without
further adjustments.
2. The angle and depth is adjusted by the two screws
(C) and the handle (D). Loosen them and adjust.
