1.
Do not touch these knobs!
24
PUSH HANDLES BRACED/PUSH BAR
A
19 cm
1. Push bar/Push handles braced
Loosen the knobs (A). The height of the push-
handles braced/pushbar can be adjusted simply
by pulling the handles upwards or pushing them
downwards. Adjust it to the height that you
require and tighten it.
It is important that you do not mix up the
upper and lower knobs on the back of the
backrest. The lower knobs lock the backrest to
the chair, and if these are loosened by mistake,
the safety of the chair may be jeopardised!
When fitting the push bar/push handles be
aware to place the wires outside the hand-
wheels. Otherwise the wires can be dam-
aged.
The push bar/push handles braced must not be
pulled up so that it protrudes more than 19
cm over the top edge of the attachment.Do
not trap your fingers between the pushhandles
brace and the neckrest attachment. (If you have
tension adjustable).
