8-bit
Mode
2
contd.
3
52
16-bit DMX
Mode Value Function
Preset recall (snap) - Default value = 0
179-182 Preset 33
183-186 Preset 34
187-190 Preset 35
191-194 Preset 36
195-198 Preset 37
199-202 Preset 38
203-206 Preset 39
207-210 Preset 40
2
211-214 Preset 41
contd. 215-218 Preset 42
219-222 Preset 43
223-226 Preset 44
227-230 Preset 45
231-234 Preset 46
235-238 Preset 47
239-242 Preset 48
243-246 Preset 49
247-250 Preset 50
251-255 Unused (no change)
Color Temperature MSB (fade) - Default value = 127
0 2000°K
↓ ↓
34 3200° K
↓ ↓
3
127-128 6500° K
↓ ↓
215 9600° K
↓ ↓
255 11000°K
Color Temperature, fine LSB (fade) - Default value = 255
4
Lower → higher
0 - 255
Table 4:
P3-100 user manual
DMX protocol: global control
