2.11 Configuring an Auto Pan

The GV-IP Speed Dome can pan up to 360° endlessly to survey the
horizontal view between 2 pre-defined positions. You can configure up to 8
sets of Auto Pan routes.
Setting Up an Auto Pan
1. Set up the vertical position of your GV-IP Speed Dome first. The
vertical direction set during or after the horizontal movement settings
will not be effective.
2. Set up the start position of the Auto Pan.
A. Use the control buttons on the PTZ control panel to move to a
desired start position.
B. Click Option on the PTZ Control Panel, click Auto Set and
select Set Auto Pan 1 Start Position.
3. Set up the end position of the Auto Pan.
A. Use the control buttons on the PTZ control panel to move to a
desired end position.
B. Click Option, click Auto Set and select Set Auto Pan 1 Stop
Position.
4. To create another Auto Pan route, repeat Steps 1 to 4, and select a
different Auto Pan number.
For details on pan speed and the duration of dome view at the start/stop
positions, see 4.11 PTZ Settings-Other, GV-IP Speed Dome GV-SD220
User's Manual on the Software CD.
Note: The zoom ratio of an Auto Pan's Start Point will persist throughout
the whole path.
