GeoVision GV-IP Speed Dome Quick Start Manual page 22

No. Name
1 Exit
Pan / Tilt
2
Control
3 Home
Zoom In /
4
Out
Focus In /
5
Out
6 Option
7 Show Preset
Description
Closes the PTZ control panel.
Moves the PTZ Camera to
left, right, left up, left down, right up and right
down.
Brings the camera view back to the home point.
Shortens (zoom in) or lengthens (zoom out) the
apparent distance between the camera and the
view.
Adjusts the sharpness of the camera view.
Brings up these functions:
•
Dome movement settings (Preset,
Sequence, Auto Pan, Cruise and Tour)
•
Image settings
•
PTZ settings
•
System settings
For detail, see PTZ Control Panel, Chapter 4,
GV-IP Speed Dome GV-SD220 User's Manual
on the Software CD.
Opens and closes the number pad.
2
GV-SD220 / SD220-S
8 directions: up, down,
17
