GV-IP Speed Dome
GV-SD220 User's Manual
Before attempting to connect or operate this product,
ISD220V10-A
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-SD220 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-SD220

Summary of Contents for GeoVision GV-SD220

  • Page 1 GV-IP Speed Dome GV-SD220 User's Manual Before attempting to connect or operate this product, ISD220V10-A please read these instructions carefully and save this manual for future use.
  • Page 2 Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Application Model Firmware Version Indoor GV-SD220 V1.00 Outdoor GV-SD220-S This Manual provides an overview of the GV-IP Speed Dome and its accessories. The instructions will guide you through the installation and use of the GV-IP Speed Dome as well.

  • Page 4: Table Of Contents

    Contents Regulatory Notices....................vi Note for Connecting to GV-System ............... vii Chapter 1 Introduction................... 1 1.1 Overview.........................1 1.2 System Requirements.....................3 1.3 Packing List ......................4 1.3.1 Indoor GV-IP Speed Dome Camera .............. 4 1.3.2 Outdoor GV-IP Speed Dome Camera ............5 1.4 Functional Panel .....................6 1.4.1 Removing the Camera Cover................
  • Page 5 4.1 Preset Settings .....................36 4.2 Cruise Settings .....................37 4.3 Auto Pan Settings ....................38 4.4 PTZ Settings- Sequence Settings .................39 4.5 PTZ Settings- Tour Settings ..................41 4.6 Image Settings- White Balance ................43 4.7 Image Settings- Auto Exposure................44 4.8 Image Settings- Color ...................46 4.8 Image Settings- Mask ...................47 4.9 Image Settings- Other...................49 4.10 PTZ Settings- Schedule ..................51...
  • Page 6 5.7.4 SNMP Settings ..................94 5.8 Management......................95 5.8.1 Date and Time Settings ................95 5.8.2 GPS Maps Settings ...................97 5.8.3 Storage Settings..................99 5.8.4 User Account...................101 5.8.5 Log Information ..................103 5.8.6 Tools......................104 5.8.7 Language ....................106 Chapter 6 Recording and Playback ..............107 6.1 Recording ......................107 6.2 Playback ......................108 6.2.1 Playback Using the Memory Card ............108 6.2.2 Playback over Network................110...
  • Page 7 Chapter 10 Smart Device Connection..............141 10.1 Android ......................142 10.1.1 Connecting to GV-IP Speed Dome ............142 10.1.2 Accessing Live View................144 10.2 Apple ........................146 10.2.1 Connecting to GV-IP Speed Dome ............147 10.2.2 Accessing Live View................148 GV-IP Speed Dome Specifications ..............150 Appendix ........................154 A.

  • Page 8: Regulatory Notices

    Regulatory Notices FCC Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 9: Note For Connecting To Gv-System

    Naming Definition GeoVision Analog and Digital Video Recording Software. The GV-System GV-System also refers to GV-Multicam System, GV-NVR System, GV-DVR System and GV-Hybrid DVR System at the same time. Note for Connecting to GV-System The GV-IP Speed Dome is designed to work with and record on GV-System, a hybrid or digital video management system.

  • Page 10: Optional Devices

    Optional Devices Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description The GV-Mount Accessories provide a comprehensive lineup of accessories for installing the outdoor GV-IP Speed Dome on GV-Mount Accessories ceiling, wall corner and pole. For details, see GV-Mount Accessories Installation Guide on the Software CD.

  • Page 11: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Overview The GV-IP Speed Dome (GV-SD220/GV-SD220-S) is a network PTZ camera designed for image quality and adaptability in various environments. This camera offers the image of 1080p at 30 fps, 720p at 60 fps and 20x optical zoom, capable of showing smooth live view with great detail.
  • Page 12 Features: • 1/2.8’’ Progressive Scan CMOS sensor • Full HD 1080p at up to 30 fps and 720p at up to 60 fps • 20x optical zoom and 12x digital zoom • H.264 and MJEPG video compression • Dual streams •...

  • Page 13: System Requirements

    Introduction 1.2 System Requirements To access GV-IP Speed Dome functions through Web browser, ensure your PC is in good network connection and use one of the following web browsers: • Microsoft Internet Explorer 7.x or later • Google Chrome • Mozilla Firefox •...

  • Page 14: Packing List

    Packing List 1.3.1 Indoor GV-IP Speed Dome Camera • Indoor GV-IP Speed Dome • Hard-Ceiling Cover • Mounting Plate • GV-IP Speed Dome Software CD • GV-NVR Software DVD...

  • Page 15: Outdoor Gv-Ip Speed Dome Camera

    Introduction 1.3.2 Outdoor GV-IP Speed Dome Camera • Outdoor GV-IP Speed Dome • Pendant Tube • Hex Keys x 2 • M6 Screws x 3 • Desiccant pack x 2 • GV-IP Speed Dome Software CD • GV-NVR Software DVD...

  • Page 16: Functional Panel

    1.4 Functional Panel To access the functional panel of the GV-SD200 / GV-SD220-S, follow the section below to remove its camera cover first. 1.4.1 Removing the Camera Cover • Indoor GV-IP Speed Dome: Rotate to remove the camera cover. Figure 1-1 •...

  • Page 17: Camera Interior

    Introduction 1.4.2 Camera Interior Figure 1-3 No. Name Function Restores all the settings to the factory default values. For details Default see 7.3 Restoring to Factory Default Settings. The status LED turns green when the power is on and fades Status when the camera is ready for use.

  • Page 18: Installing The Gv-Ip Speed Dome

    1.5 Installing the GV-IP Speed Dome 1.5.1 Indoor GV-IP Speed Dome: Hard-Ceiling Mount Required Items • Indoor packing (supplied) • ceiling screws x 3 (user-prepared) Figure 1-4 1. Secure the mounting plate to the ceiling with self-prepared screws. Figure 1-5...
  • Page 19 Installing the GV-IP Speed Dome 2. Secure the indoor GV-IP Speed Dome to the mounting plate. A. Loosen the screw on the mounting plate Figure 1-6 B. Align the camera to the mounting plate and rotate the camera body to the right. Figure 1-7 C.

  • Page 20: Outdoor Gv-Ip Speed Dome: Wall Pendant Mount

    1.5.2 Outdoor GV-IP Speed Dome: Wall Pendant Mount Required Items • Outdoor packing (supplied) • ceiling screws x 4 (user-prepared) Figure 1-8 1. Insert the desiccant to the camera. IMPORTANT: Be sure the desiccant is concealed in the GV-IP Speed Dome within 2 minutes of opening the desiccant pack.
  • Page 21 Installing the GV-IP Speed Dome B. Unpack one desiccant and insert the desiccant to one of the indicated places. Figure 1-10 C. Follow step 1A to secure the camera cover with the supplied hex key. 2. Thread the camera cable through the pendant tube and lock the camera to the pendant tube.

  • Page 22: Connecting The Camera

    1.6 Connecting the Camera Follow the steps below to connect the camera. Refer to The Data Cable and I/O Wire Definition in this section for detailed information. 1. Connect a standard network cable to the Ethernet cable of the camera. 2.

  • Page 23: Chapter 2 Getting Started

    Note: If your router does not support DHCP, the default IP address will be 192.168.0.10. In this case, it is strongly suggested to modify the IP address to avoid IP address conflict with other GeoVision IP device on the same LAN. To change the IP address, see Changing the IP Address later in this section.
  • Page 24 Click the Name or Mac Address column to sort. Figure 2-2 Find the Mac Address of the camera to see its IP address. Changing the IP Address To modify the static IP address or set the camera to a public dynamic IP address, log in the Web interface to access the network setting page.
  • Page 25 Installing the GV-IP Speed Dome 4. Select Dynamic IP address, Static IP address or PPPoE and type the required network information. 5. Click Apply. The camera is now accessible by entering the assigned IP address on the web browser. Important: If your camera uses a public dynamic IP address via PPPoE, use the dynamic DNS Service to obtain a domain name linked to the camera’s changing IP address first.

  • Page 26: Accessing Your Surveillance Images

    4. A video image, similar to the example in Figure 3-1, is now displayed on your browser. Note: To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a once-only installation of GeoVision’s ActiveX component onto your computer.

  • Page 27: Configuring The Basics

    Installing the GV-IP Speed Dome 2.3 Configuring the Basics Once you have installed and logged in the GV-IP Speed Dome, you are ready to configure some of its primary settings through the Web interface: • Date and time adjustment: see 5.8.1 Date & Time Settings. •...

  • Page 28: Chapter 3 Guest Mode And Live View Panel

    Chapter 3 Guest Mode and Live View Panel This section introduces the features of the guest mode and the live view window. Main Page of Guest Mode Figure 3-1...

  • Page 29: The Live View Window

    Getting Started 3.1 The Live View Window In the left menu, click Live View, and then select Camera to see the live video. Figure 3-2 No. Name Function Play Plays live video. Stop Stops playing video. Microphone Talks to the surveillance area from the local computer. Speaker Listens to the audio around the camera.
  • Page 30 No. Name Function Clicks to switch to one of the three visual PTZ control modes: Visual PTZ Fixed Direction Move, Random Move or Center Move. For details, see 3.13 Visual PTZ. Click to return the dome view to the home position. To set up a PTZ Home home position, see 4.11 PTZ Settings-Other.

  • Page 31: The Control Panel Of The Live View Window

    Getting Started 3.2 The Control Panel of the Live View Window To open the control panel of the Live View window, click the arrow button on top of the viewer. You can access the following functions by using the right and left arrow buttons on the control panel.

  • Page 32: Snapshot Of A Live Video

    3.3 Snapshot of a Live Video To take a snapshot of live video, follow these steps: 1. Click the Snapshot button (No. 5, Figure 3-2). The Save As dialog box appears. 2. Specify Save in, type the File name, and select JPEG or BMP for Save as Type. You may also choose to display the camera name and/or the date, the text color and image quality for the snapshot.

  • Page 33: Wide Angle Dewarping

    Getting Started 3.5 Wide Angle Dewarping The live view can be curved especially near the corners. Use this function to correct the warping of live view. 1. Right-click the live view to display a drop-down list and select Wide Angle Setting. The Wide Angle Dewarping Setting window appears.

  • Page 34: Picture-In-Picture And Picture-And-Picture View

    3.6 Picture-in-Picture and Picture-and-Picture View The full screen mode provides two types of close-up views: Picture-in-Picture (PIP) and Picture-and Picture (PAP). The two views are useful to provide clear and detailed images of the surveillance area. Picture-in-Picture View With the Picture-in-Picture (PIP) view, you can crop the video to get a close-up view or zoom in on the video.
  • Page 35 Getting Started Picture-and-Picture View With the Picture-and-Picture (PAP) view, you can create a split video effect with multiple close-up views on the image. A total of 7 close-up views can be defined. Figure 3-6 1. Right-click the live view and select PAP. A row of three inset windows appears at the bottom.

  • Page 36: Alarm Notification

    3.7 Alarm Notification After input triggers and motion detection, you can be alerted by a pop-up live video and view up to four captured images. Pop-up live video Captured images Figure 3-7 To configure this function, click the Show System Menu button (No. 12, Figure 3-2), and select Alarm Notify.

  • Page 37: Video And Audio Configuration

    Getting Started 3.8 Video and Audio Configuration You can enable the microphone and speaker for two-way audio communication and adjust the set the number of frames to keep for live view buffer. Click the Show System Menu button (No. 12, Figure 3-2), and select Video and Audio Configuration.

  • Page 38: Remote Configuration

    3.9 Remote Configuration You can upgrade the device firmware over the network. Click the Show System Menu button (No. 12, Figure 3-2), and select Remote Config. The Remote Config dialog box will appear. [Firmware Upgrade] In this tab, you can upgrade the firmware over the network. For details, see Chapter 6 Advanced Applications.

  • Page 39: Ptz Control

    Getting Started 3.12 PTZ Control The PTZ control panel is a virtual panel used to control the dome view. With the control panel, the Guest user can carry out Pan, Tilt, Zoom, Focus and Iris functions as well as pre-defined Preset, Sequence, Auto Pan, Cruise and Tour movements.

  • Page 40: Visual Ptz

    3.13 Visual PTZ In addition to the PTZ Control Panel, you may also use a minimized panel, the visual PTZ control panel to operate your GV-IP Speed Dome. This panel can be used to perform all the functions of the guest PTZ control panel except iris control. For functions of guest PTZ control panel, see 3.12 PTZ Control.
  • Page 41 Getting Started Set Color: Changes the color of the panel. Three kinds of colors are available: Red, Green and Blue. Transparent Degree: Adjusts the transparency level of the panel. Ten levels range from 10% (fully transparent) to 100% (fully opaque).

  • Page 42: I/O Control

    3.14 I/O Control The I/O Control window provides real-time graphic displays of camera and I/O status, and alarm events. Additionally, you can force output to be triggered. Figure 3-14 • To display the I/O control window, click the I/O Control button (No. 8, Figure 3-2). •...

  • Page 43: Chapter 4 Ptz Control Panel

    Chapter 4 PTZ Control Panel In this chapter, you will be guided through setup steps for various type of dome view movements (including Preset, Cruise, Auto Pan, Sequence and Tour), image quality settings, (including white balance, exposure and color parameters), schedule settings and PTZ settings.
  • Page 44 Accessing the PTZ Configuration Dialog Box: From the PTZ control panel (Figure 4-1), click Option and select Setup. This dialog box appears. Figure 4-2 PT Speed: determines the speed of panning and tilting of the dome view. The drop-down list contains 5 speed settings: 1 is the slowest speed and 5 the fastest speed. Max Preset: determines the number of Preset points for configuration.
  • Page 45 PTZ Control Panel Start Menu: Click Open to open PTZ configuration dialog box which contains Image Settings, PTZ settings and general settings related to PTZ function. Figure 4-3 Click OK to save and exit the setup.

  • Page 46: Preset Settings

    4.1 Preset Settings You can set up a preset position toward which the dome view moves. Up to 255 preset points can be configured and saved. Setting Up a Preset 1. To set up a preset position, use the Pan/Tilt Control keys on the PTZ Control Panel to move the dome to a desired position in Live View.

  • Page 47: Cruise Settings

    PTZ Control Panel 4.2 Cruise Settings You can set up a route consisting of different directions, angles, and zooms for the GV-IP Speed Dome to follow. Up to 4 Cruises can be created. Setting Up a Cruise 1. Click Option (Figure 4-1) on the PTZ Control Panel, click Auto Set and select Set Cruise 2.

  • Page 48: Auto Pan Settings

    4.3 Auto Pan Settings The GV-IP Speed Dome can pan up to 360° endlessly to survey the horizontal view between 2 user-defined positions. You can configure up to 8 sets of Auto Pan mode. Setting Up an Auto Pan 1. Set up the vertical position of your GV-IP Speed Dome first. The vertical direction set during or after the horizontal movement settings will not be effective.

  • Page 49: Ptz Settings- Sequence Settings

    PTZ Control Panel 4.4 PTZ Settings- Sequence Settings You can have the dome view move in a series of predefined movements, called a Sequence. Create a Sequence by linking a number of presets points. Up to 8 Sequences can be created and a minimum of 2 preset points must be selected for a Sequence route to work.
  • Page 50 Starting and Stopping a Sequence To start the dome view on a Sequence route, click Option (Figure 4-1) on the PTZ Control Panel, click Auto Go and select a Go Sequence number which has been previously set. The dome view will continue moving once a Sequence is started. To stop the movements, click a Pan/Tilt Control key, home key, zoom button or focus button on the PTZ Control Panel.

  • Page 51: Ptz Settings- Tour Settings

    PTZ Control Panel 4.5 PTZ Settings- Tour Settings You can set up your GV-IP Speed Dome to move in a combination of preset positions, Sequence, Cruise and Auto Pan. You can configure up to 8 Tour routes. Figure 4-5 Setting Up a Tour 1.
  • Page 52 Starting and Stopping a Tour To start the GV-IP Speed Dome on a Tour route, click Option (Figure 4-1) on the PTZ Control Panel, click Auto Go and select a Go Tour number which has been previously set. An enabled Tour will repeat until it is stopped by clicking a Pan/Tilt Control key, home key, zoom button or focus button on the PTZ Control Panel.

  • Page 53: Image Settings- White Balance

    PTZ Control Panel 4.6 Image Settings- White Balance The White Balance setting is used to adjust the colors of camera image so that it reflects normal coloring under different environment lighting. Figure 4-6 Auto: The camera automatically performs color adjustments. This option is suitable for environments with unchanging lightings.

  • Page 54: Image Settings- Auto Exposure

    4.7 Image Settings- Auto Exposure Figure 4-7 Auto Exposure: provides controls on camera exposure. Select Full Auto, Shutter Priority, Iris Priority or Bright Priority. The default is Full Auto. Full Auto: The camera adjusts its exposure automatically. By enabling this option, you can also adjust the Slow Shutter below.
  • Page 55 PTZ Control Panel Slow Shutter: This option is only available under the Full Auto mode. The shutter speed determines how long the image sensor is exposed to light. For clearer images in low light conditions, select ON to enable slow shutter speed.

  • Page 56: Image Settings- Color

    4.8 Image Settings- Color The Color settings are used to adjust color contrast, sensitivity and gain. Figure 4-8 Luminance (low lux): Enable this function to make low-light views clearer. Color Gain: Adjusts the contrasts of the dome view.

  • Page 57: Image Settings- Mask

    PTZ Control Panel 4.8 Image Settings- Mask The Mask is used to block out sensitive areas from view. You can create and save up to 8 Masks. The Mask size will stay proportional to the zoom, which increases when zoomed in and decreases when zoomed out.
  • Page 58 2. To disable a Mask, select the Mask number from Mask, select Off and click the Save button. 3. To create a new Mask, select a different Mask number and follow steps 1B to 1D. 4. To delete a Mask, select the Mask number from Mask, select Clear Mask and click Save button.

  • Page 59: Image Settings- Other

    PTZ Control Panel 4.9 Image Settings- Other Figure 4-10 Digital Zoom: With this option, users can enable or disable the 12x Digital Zoom. The Digital Zoom will be activated after the Optical Zoom level is fully reached. The default setting is Off. Focus: Sets the focus mode of the dome.
  • Page 60 Backlight: Backlight Compensation (BLC) is used to compensate AGC in adjusting color intensity. For scenes with strong light in the background and dim light in the foreground, AGC is not effective because AGC averages the light intensity of a whole frame. BLC compensates for this characteristic by restricting AGC to adjust color intensity of a specific area.

  • Page 61: Ptz Settings- Schedule

    PTZ Control Panel 4.10 PTZ Settings- Schedule You can set up a schedule for the dome to perform Preset, Sequence, Auto Pan, Cruise or Tour during a specified time. Up to 8 sets of schedule can be configured and saved. Figure 4-11 1.

  • Page 62: Ptz Settings- Other

    4.11 PTZ Settings– Other This page contains speed and duration settings of Auto Pan and PT. Figure 4-12 Auto Pan: An Auto Pan is a pan movement of the dome view between two user-defined positions. For setup steps, see 4.3 Auto Pan Mode Settings. Speed: Select the panning speed.

  • Page 63: System Configuration

    PTZ Control Panel 4.12 System Configuration Figure 4-13 Freeze: Skip showing camera images while traveling from one preset to another. This function is disabled by default. Mechanic Flip: The dome view rotates 180° when it is tilted to the maximum angle (vertically 0°...
  • Page 64 Auto Pan: When the Delay Time is up, the dome will automatically perform the selected Auto Pan number. To configure an Auto Pan, see 4.3 Auto Pan Settings. Cruise: When the Delay Time is up, the dome will automatically perform the selected Cruise number.

  • Page 65: Chapter 5 Administrator Mode

    Chapter 5 Administrator Mode The Administrator can access and configure the GV-IP Speed Dome over the network. The configuration categories include: Video and Motion, I/O Control, Events and Alerts, Monitoring, Recording Schedule, Remote ViewLog, Network, and Management. Figure 5-1...
  • Page 66 Corresponding Section for Configuration Menu Find the topic of interest by referring to the indicated section. 5.1.1 Video Settings 5.1 Video and Motion 5.1.2 Motion Detection 5.1.3 Text Overlay 5.2.1 Input Settings 5.2 I/O Control 5.2.2 Output Settings 5.3.1 Email 5.3.2 FTP 5.3.3 Center V2 5.3.4 VSM...

  • Page 67: Video & Motion

    Configuration Menu 5.1 Video & Motion The GV-IP Speed Dome supports dual streams, Streaming 1 and Streaming 2, which allow separate codec and resolutions settings for a single video transmission. In a bandwidth-limited network, such as mobile phone surveillance, this dual-stream feature allows you to view live video in lower resolution and codec (Streaming 2), and record in highest resolution 1920 x 1080 and codec H.264 (Streaming 1) at the same time.

  • Page 68: Video Settings

    5.1.1 Video Settings...
  • Page 69 Configuration Menu Figure 5-2 [Name] Rename the camera. The camera name will appear on the Live View. To display the camera name, see 3.10 Camera Name Display. [Connection Template] Select the type of your network connection. Unless you select Customized, this option will automatically bring up the recommended video resolution, frame rate, bandwidth and GOP size.
  • Page 70 [Bandwidth Management] When using the H.264 codec, it is possible to configure the bitrate settings to control bandwidth usage. VBR (Variable Bitrate): The quality of the video stream is kept as constant as possible at the cost of a varying bitrate. The bandwidth is much more efficiently used than a comparable CBR.
  • Page 71 Configuration Menu [Text Overlay Settings] Overlaid with camera name: Includes camera names on live and recorded videos. Overlaid with date stamps: Includes date stamps on live and recorded videos. Overlaid with time stamps: Includes time stamps on live and recorded videos. Overlaid with digital input description name: Includes the names of selected inputs on live and recorded videos.

  • Page 72: Motion Detection

    5.1.2 Motion Detection Motion detection is used to generate an alarm whenever movement occurs in the dome view. You can configure up to 8 detection zones with different sensitivity values. Create at least one detection zone to enable this function. Figure 5-3 1.
  • Page 73 Configuration Menu 6. For the camera to ignore environmental changes such as rain or snow, select the Ignore environmental changes. 7. To reduce video noise when the lighting condition changes, select Noise Tolerance. 8. To trigger the alarm output when motion is detected, select the Output 1 and click the Apply button.

  • Page 74: Text Overlay

    5.1.3 Text Overlay The Text Overlay allows you to overlay any text in any place on the camera view. Up to 16 text messages can be created on one camera view. The overlaid text will be saved in the recordings. Figure 5-4 1.

  • Page 75: I/O Control

    Configuration Menu 5.2 I/O Control This section introduces how to configure the I/O devices connected to the GV-IP Speed Dome. 5.2.1 Input Settings The GV-IP Speed Dome can connect up to 4 input devices.
  • Page 76 Figure 5-5 Name: Edit the input name. Normal State: Set up the input state to trigger actions by selecting Open Circuit (N/O) or Grounded Circuit (N/C). Latch Mode: Enable the mode to have a momentary output alarm. Trigger Digital Output Relay: Select the output to be triggered once the input is activated.

  • Page 77: Output Setting

    Configuration Menu 5.2.2 Output Setting The GV-IP Speed Dome can connect 1 output device. Figure 5-6 Select Enable to start the output device. Choose the output signal that mostly suits the device you are using: N/O (Open Circuit), N/C (Grounded Circuit), N/O Toggle, N/C Toggle, N/O Pulse and N/C Pulse.

  • Page 78: Events & Alerts

    5.3 Events & Alerts For the events of motion detection or I/O trigger, the Administrator can set up two triggered actions: 1. Send a captured still image by e-mail or FTP. 2. Notify Center Monitoring Stations such as Center V2, VSM or GV-GIS, by video or text alerts.

  • Page 79: E-Mail

    Configuration Menu 5.3.1 E-mail After a trigger event, the GV-IP Speed Dome can send an e-mail to a remote user containing a captured image. Important: To send e-mail alert upon motion, be sure to set up the detection area on the Motion Detection page.
  • Page 80 7. If the SMTP Server needs authentication, select Need authentication to login and type a valid Username and Password to log in the SMTP server. If the SMTP Server needs a secure connection (SSL), select This server requires a secure connection. 8.

  • Page 81: Ftp

    Configuration Menu 5.3.2 FTP You can also send the captured image to a remote FTP server for alerts. Important: To send FTP alert upon motions, be sure to set up the detection area on the Moti Detection page. For details, see 5.1.2 Motion Detection. Figure 5-8 [Upload to an FTP Server] 1.
  • Page 82 6. Alerts interval time in minute: Specify the interval between FTP alerts. The interval can be between 0 and 60 minutes. The option is useful for frequent event occurrence. Any event triggers during the interval period will be ignored. 7. FTP-Alarm Settings: Select to automatically send a snapshot to the FTP Server upon motion detection or input trigger.

  • Page 83: Center V2

    Configuration Menu 5.3.3 Center V2 After a motion or an I/O triggered event, the central monitoring station Center V2 can be notified by live videos and text alerts. Up to two Center V2 servers can be connected. For live monitoring through Center V2, you must already have a subscriber account on each of the Center V2 server.
  • Page 84 3. Port Number: Match the port to Port 2 on Center V2. Or keep the default value 5551. For details, see 8.1 Center V2. 4. User Name: Type a valid user name to log in to Center V2. 5. Password: Type a valid password to log in to Center V2. 6.

  • Page 85: Vsm

    Configuration Menu 5.3.4 VSM After a motion or an I/O triggered event, the central monitoring station VSM can be notified by text alerts. Up to two VSM servers can be connected. For live monitoring through VSM, you must already have a subscriber account on each of the VSM server. Important: To notify the VSM upon motions, be sure to set up the detection area on the Moti Detection page.
  • Page 86 3. Port Number: Match the port to Port 2 on VSM. Or keep the default value 5609. For details, see 8.2 VSM. 4. User Name: Type a valid user name to log into VSM. 5. Password: Type a valid password to log into VSM. 6.

  • Page 87: Backup Center

    Configuration Menu 5.3.5 Backup Center The connection to the GV-Backup Center allows you to back up another copy of recordings and system log to the GV-Backup Center on an offsite location while the camera is saving these data to the memory card. The GV-Backup Center provides a PC-based storage and backup solution.
  • Page 88 To enable connection to GV-Backup Center: 1. Activate Link: Enable the connection to the GV-Backup Center. 2. Host Name or IP Address: Type the host name or IP address of the GV-Backup Center. 3. Port Number: Match the communication port on the GV-Backup Center. Or keep the default value 30000.

  • Page 89: Gv-Video Gateway / Gv-Recording Server

    Configuration Menu 5.3.6 GV-Video Gateway / GV-Recording Server The GV-IP Speed Dome can be connected with up to two GV-Video Gateway / GV-Recording Server. To send the video images to the GV-Video Gateway or GV-Recording Server, you must already have an account on each of the GV-Video Gateway / GV-Recording Server with the user name and password specified below.
  • Page 90 To enable connection to GV-Video Gateway / GV-Recording Server: 1. Activate Link: Enable the monitoring through GV-Video Gateway / GV-Recording Server. 2. Host Name or IP Address: Type the host name or IP address of the GV-Video Gateway / GV-Recording Server. 3.

  • Page 91: Viewlog Server

    Configuration Menu 5.3.7 ViewLog Server The ViewLog Server is designed for remote playback function. This server allows you to remotely access the recorded files saved at the GV-IP Speed Dome and play back video with the ViewLog player. Select Enable to activate the built-in server. Keep the default port 5552 or modify it if necessary.

  • Page 92: Rtsp / 3Gpp

    5.3.8 RTSP / 3GPP The RTSP / 3GPP Server enables video and audio streaming to your 3G-enabled mobile phone. Figure 5-14 Activate Link: Enable the RTSP / 3GPP service. RTSP/TCP Port: Keep the default value 8554, or modify it if necessary. RTP/UDP Port: Keep the default range from 17300 to 17319, or modify it if necessary.

  • Page 93: Monitoring

    Configuration Menu 5.4 Monitoring You can start I/O monitoring manually or by schedule. Figure 5-15 [Manual] Manually activates motion detection and I/O monitoring. Select one of the following options and then click the Start button. Select all: Manually starts both motion detection and I/O monitoring. Camera: Manually starts recording.

  • Page 94: Recording Schedule

    5.5 Recording Schedule The schedule settings activate recording and I/O monitoring during specific time periods each day. 5.5.1 Recording Schedule Settings You can set up the schedule for recording. Figure 5-16 Span 1- Span 3: Set a different recording mode for each time span during the day. Each day can be divided into 3 time spans, shown as Span 1, Span2, and Span 3.

  • Page 95: I/O Monitoring Settings

    Configuration Menu 5.5.2 I/O Monitoring Settings You can set the I/O Monitoring Schedule Settings to enable I/O monitoring. Figure 5-17 Span 1-3: Set different time frames during the day to start I/O monitoring. Each day can be divided into 3 time frames, represented by Span 1 to Span 3. The time frame you specify is effective from Monday through Sunday.

  • Page 96: Remote Viewlog

    5.6 Remote ViewLog With the Remote ViewLog function, you can play back the files recorded at the GV-IP Speed Dome over TCP/IP network. For first-time users, you need to install the Remote ViewLog program from the Software CD to the local computer. For remote access to the camera, the ViewLog Server built in the unit must be enabled.

  • Page 97: Network

    Configuration Menu 5.7 Network The Network section includes some basic but important network configurations that enable the GV-IP Speed Dome to be connected to a TCP/IP network. 5.7.1 LAN Configuration According to your network environment, select among Static IP, DHCP and PPPoE. Figure 5-18 [LAN Configuration] Dynamic IP address: The network environment has a DHCP server which will automatically...
  • Page 98 Static IP address: Assign a static IP or fixed IP to the camera. Type the camera’s IP address, Subnet Mask, Router/Gateway, Primary DNS server and Secondary DNS server. Parameters Default IP address 192.168.0.10 Subnet Mask 255.255.255.0 Router/Gateway 192.168.0.1 Primary DNS server 192.168.0.1 Secondary DNS server 192.168.0.2...

  • Page 99: Advanced Tcp/Ip

    Configuration Menu 5.7.2 Advanced TCP/IP This section introduces the advanced TCP/IP settings, including DDNS Server, HTTP port, streaming port and UPnP.
  • Page 100 2. Service Provider: Select the DDNS service provider you have registered with. 3. Host Name: Type the host name used to link to the GV-IP Speed Dome. For the users of GeoVision DDNS Server, it is unnecessary to fill the field because the system will detect the host name automatically.
  • Page 101 Configuration Menu The HTTP port enables connecting the GV-IP Speed Dome to the Web. For security integration, the Administrator can hide the server from the general HTTP port by changing the default HTTP port of 80 to a different port number within the range of 1024 through 65535. [HTTPS Settings] By enabling the Hypertext Transfer Protocol Secure (HTTPS) settings, you can access the camera through a secure protocol.
  • Page 102 the bandwidth amount. This value ranges from 0 to 63 in decimal format. The default value is 0 which means QoS is disabled. Click Apply to finish. [Network Connection Check Settings] When the network connection check is enabled, the GV-IP Speed Dome will check for Internet connection and reboots automatically when it is disconnected from the Internet.

  • Page 103: Ip Filter

    Configuration Menu 5.7.3 IP Filter The Administrator can set IP filtering to restrict access to the GV-IP Speed Dome. Figure 5-20 To enable the IP Filter function: 1. Enable IP Filtering: Enable the IP Filtering function. 2. Filtered IP: Type the IP address you want to restrict the access. 3.

  • Page 104: Snmp Settings

    5.7.4 SNMP Settings The Simple Network Management Protocol (SNMP) allows you to monitor the status of the GV-IP Speed Dome through SNMP network management software. Figure 5-21 1. Select Enable SNMPv1 SNMPv2c to enable the function. 2. To enable access to Read/Write community, type a community string. This will serve as a password to allow read and write access to the GV-IP Speed Dome from the SNMP software.

  • Page 105: Management

    Configuration Menu 5.8 Management The Management section includes the settings of data and time, GPS Maps and user account. Also you can view the firmware version and execute certain system operations. 5.8.1 Date and Time Settings The date and time settings are used for date and time stamps on the image. Figure 5-22...
  • Page 106 [Date & Time on GV-IP Speed Dome] Displays the current date and time on the GV-IP Speed Dome. [Time Zone] Sets the time zone for local settings. Select Enable Daylight Saving Time to automatically adjust the GV-IP Speed Dome for daylight saving time. Type the Start Time and End Time to enable the daylight saving function.

  • Page 107: Gps Maps Settings

    Configuration Menu 5.8.2 GPS Maps Settings The Maps Settings allows you to see the location of your GV-IP Speed Dome on Google maps, without the need of a GPS device. To see the location of your GV-IP Speed Dome on maps: 1.
  • Page 108 4. Click Open. A warning message appears. Figure 5-26 5. Right-click the warning message and select Allow Blocked Content. The map will be displayed. The icon indicates the location of your GV-IP Speed Dome. In the upper right corner you have options to view different map formats, such as Satellite and Hybrid. Figure 5-27...

  • Page 109: Storage Settings

    Configuration Menu 5.8.3 Storage Settings Based on Linux ext3 file system, the GV-IP Speed Dome supports memory cards for video and audio recordings. You need to format the memory card by using the following Storage Settings. After being formatted, the memory card will be ready to use by Linux OS of the camera.
  • Page 110 [Disk Information] This section shows the details of the attached storage devices. [Partition Information] This section shows the partition details of the attached storage devices. To add a memory card: 1. Insert the memory card to the camera. 2. Click the Format button. 3.

  • Page 111: User Account

    Configuration Menu 5.8.4 User Account You can change the login name and password of Administrator, Guest and FTP Server User. • The default Administrator login name and password are admin. • The default Guest login name and password are guest. To allow a Guest user log in without entering the username and password, select Disable authentication for guest account.
  • Page 112 Note: You can also access this User Account interface simply by executing a CGI command. See Appendix A.

  • Page 113: Log Information

    Configuration Menu 5.8.5 Log Information The log contains dump data that is used by service personnel for analyzing problems. Figure 5-30...

  • Page 114: Tools

    5.8.6 Tools This section allows you to execute certain system operations and view the firmware version. Figure 5-31...
  • Page 115 Configuration Menu [Host Settings] Enter a descriptive name for the GV-IP Speed Dome. [Auto Reboot Setup] Select Enable to activate automatic reboot and specify the time for reboot in the sub fields below. Day Interval: Type the day interval between the reboots. Reboot Time: Use the drop-down list to specify the time for automatic reboot.

  • Page 116: Language

    5.8.7 Language You can change the language for the Web interface. Figure 5-32 Use the Language drop-down list to select a language for the Web interface. By default, the language on the Web interface will be the same with the one used for the operating system.

  • Page 117: Chapter 6 Recording And Playback

    Recording and Playback Chapter 6 Recording and Playback The GV-IP Speed Dome can record video and audio directly to the memory card. You can play back the recorded files on the GV-System or over the TCP/IP network. Note: See Note for Connecting to GV-System at the beginning of the manual. 6.1 Recording To enable the recording function: 1.

  • Page 118: Playback

    6.2 Playback You can use the following methods to play back video files recorded at the GV-IP Speed Dome: • Playback by using the memory card by connecting it directly to the GV-System through a memory card reader • Playback by using the Remote ViewLog function over the TCP/IP network •...
  • Page 119 Recording and Playback 4. Click the Advanced button , select Reload Database and click Video Server/Compact DVR. This dialog box appears. Figure 6-2 5. Click Add to assign the hard drive. 6. Click OK to load the data to the ViewLog for playback. Note: IFS Driver supports Windows NT / 2000 / XP / Windows 7.

  • Page 120: Playback Over Network

    6.2.2 Playback over Network You can also play back the files recorded at the GV-IP Speed Dome over TCP/IP network using the Remote ViewLog function. 1. The camera needs to allow the remote access with ViewLog Server activated. See 5.3.7 ViewLog Server. 2.

  • Page 121: Access To The Recorded Files Through Ftp Server

    You can play back the downloaded files of AVI format on Media Player. For details to download files, see [Act as FTP Server], 5.3.2 FTP. Note: To play back videos, ensure you have installed Geovision codec on the computer. The codec is available on the Software CD. If you have installed the Remote Playback...

  • Page 122: Playback Of Daylight Saving Time Events

    6.2.4 Playback of Daylight Saving Time Events On GV-System, you can retrieve and play back the events recorded during the Daylight Saving Time (DST) period from the GV-IP Speed Dome. You can also connect the memory card to GV-System for playback. The following instructions describe how to retrieve the recorded files from the GV-IP Speed Dome over network.

  • Page 123: Chapter 7 Advanced Applications

    This chapter introduces more advanced applications. 7.1 Upgrading System Firmware GeoVision periodically updates the latest firmware to the company website. You can update your GV-IP Speed Dome firmware through the Web interface or GV IP Device Utility included in the Software CD.

  • Page 124: Using The Web Interface

    7.1.1 Using the Web Interface 1. In the Live View window, click the Show System Menu button (No. 12, Figure 3-2) and select Remote Config. This dialog box appears. Figure 7-1 2. Click the Browser button to locate the firmware file (.img) saved at your local computer. 3.

  • Page 125: Using The Gv Ip Device Utility

    Advanced Applications 7.1.2 Using the GV IP Device Utility The IP Device Utility provides a direct way to upgrade the firmware to multiple GV-IP Speed Domes. Note the computer used to upgrade firmware must be under the network of the GV-IP Speed Dome.
  • Page 126 5. Click the Firmware Upgrade tab. This dialog box appears. Figure 7-4 5. Click the Browse button to locate the firmware file (.img) saved at your local computer. 6. If you like to upgrade all the GV-IP Speed Domes in the list, check Upgrade all devices. 7.

  • Page 127: Backing Up And Restoring Settings

    Advanced Applications 7.2 Backing Up and Restoring Settings With the IP Device Utility included on the Software CD, you can back up the configurations in the GV-IP Speed Dome, and restore the backup data to the current unit or import it to another unit.
  • Page 128 To restore the settings: 1. In Figure 7-3, click the Import Settings tab. This dialog box appears. Figure 7-6 2. Click the Browse button to locate the backup file (.dat). 3. Select Upgrade all devices to import the settings into the same type of device in the same LAN.

  • Page 129: Restoring To Factory Default Settings

    Advanced Applications 7.3 Restoring to Factory Default Settings The settings and default restoration of GV-IP Speed Dome are divided into two parts: system settings, which are all the settings on Web interface, excluding PTZ control panel; and PTZ configuration settings (Figure 4-3). You may choose to load all the settings, or just one part of the settings.
  • Page 130 To restore PTZ configuration settings only: 1. Access the PTZ Configuration dialog box. For details, see Calling Up the PTZ Control Panel and Accessing the PTZ settings, Chapter 4. 2. On the PTZ Configuration dialog box (Figure 4-3), select System Configuration. This dialog box appears.

  • Page 131: Verifying Watermark

    Advanced Applications 7.4 Verifying Watermark The watermark is an encrypted and digital signature embedded in the video stream during the compression stage, protecting the video from the moment of creation. Watermarking ensures that an image is not edited or damaged after it is recorded. To enable the watermark function, see [Watermark Setting], 5.1.1 Video Settings.

  • Page 132: The Watermark Proof Window

    7.4.3 The Watermark Proof Window Figure 7-8 The controls in the window: No. Name Description Open File Opens the recording. First Frame Goes to the first frame of the file. Play Plays the file. Previous Frame Goes to the previous frame of the file. Next Frame Goes to the next frame of the file.

  • Page 133: Downloading Videos From The Sd Card

    7.5.1 Installing the GV-SDCardSync Utility 1. Download the GV-SD Card Sync Utility program from http://ftp.geovision.tw/FTP/neo/Utility/GvSDCardSync_Setup.zip 2. Execute the GV-SDCard Sync Utility program. The main window and the Setting window appear. The Setting window pops up automatically upon first execution. Otherwise, click the Setting button on the main window.
  • Page 134 3. To configure synchronization, network and startup settings, see the steps below. Figure 7-10 [Synchronization] Synchronize automatically at an interval: Automatically synchronize videos from SD cards to a local folder at the specified interval. Synchronize automatically at: Automatically synchronize videos from SD cards to a local folder at the specified time.
  • Page 135 DVR Configurations 4. By default, downloads are saved to :\GvSDCardSync and are not recycled automatically. To configure the storage and recycling settings, select the Storage tab on the Setting window. This page appears. Figure 7-11 [Recycle] Recycle when the storage space is less than (GB): Specify a minimum free space of your local storage for file recycling.

  • Page 136: The Gv-Sdcardsync Utility Window

    7.5.2 The GV-SDCardSync Utility Window After you have installed the GV-SDCardSync Utility, point to Start, select Programs, select GV-SDCardSync and select to launch the program. This window appears. Figure 7-12 No. Name Description Plays downloaded recordings of the selected GV-IP Speed dome using the ViewLog player.

  • Page 137: Chapter 8 Dvr Configurations

    DVR Configurations Chapter 8 DVR Configurations The GV-System provides hybrid solution, integrating the digital videos from GV-IP Speed Dome with other analog videos. For digital videos, the GV-System provides the complete video management, such as video viewing, recording, playback, alert settings and almost every feature of the system.

  • Page 138: Setting Up Ip Cameras

    8.1 Setting Up IP Cameras Follow the steps below to manually connect your GV-IP Speed Dome to GV-System. Note: The following instructions are based on V8.5.5 software and user interfaces. 1. On the GV-System’s main screen, click the Configure button, select System Configure, select Camera Install and click IP Camera Install.
  • Page 139 3. Type the IP address, username and password of the GV-IP Speed Dome. Modify the default HTTP port if necessary. 4. Select GeoVision from the Brand drop-down list and select GV-SD220 from the Device drop-down list. This dialog box appears.
  • Page 140 Dual Stream: Click this button to set the codec type to H.264 in the main stream and the sub stream with the resolutions listed below. Port: Modify the video streaming port number if necessary. Stream Number: Click the Query button and select Single Stream or Dual Stream. Codec type: The live view codec and resolution settings are displayed here.

  • Page 141: Customizing Camera Settings

    DVR Configurations 8.1.1 Customizing Camera Settings After the GV-IP Speed Dome is connected and assigned with a display channel, you can configure the camera’s settings such as frame rate, codec type and resolution. Right-click the camera to see the following list of options: Figure 8-6 Change Resolution: Changes the display ratio, live view resolution and record resolution.
  • Page 142 Frames to keep in live view buffer: Specifies the number of frames to keep in the live view buffer. Recording Codec Format: Specifies whether to record in standard or GeoVision type of JPEG or H.264 codec. GIS Setting: Records the video with the GPS data. To record the GPS data, remember to also enable the GIS function of the GV-System (Configure button <...

  • Page 143: Remote Monitoring With Multi View

    DVR Configurations 8.2 Remote Monitoring with Multi View You can use the Multi View to monitor the video and I/O devices connected to the GV-IP Speed Dome. Connecting to GV-IP Speed Dome The Multi View program is available in the GV-System applications, and is also included in the Software CD as an independent program.
  • Page 144 6. Select GV-IP Camera, GV-IP Speed Dome from the Device drop-down list. Type the host name, IP address, user name and password of the GV-IP Speed Dome. Modify the default VSS port 10000 if necessary. Figure 8-7 7. Click Save to establish connection. For details on the Multi View functions, see “Multi View Viewer”, Chapter 8, DVR User’s Manual on the GV-NVR Software DVD.

  • Page 145: Remote Monitoring With E-Map

    DVR Configurations 8.3 Remote Monitoring with E-Map You can use the Remote E-Map to monitor the video and I/O devices connected to the GV-IP Speed Dome. Creating an E-Map for the GV-IP Speed Dome With the E-Map Editor, you can create an E-Map for the GV-IP Speed Dome and I/O devices connected to the dome.
  • Page 146 DVR User’s Manual on the GV-NVR Software DVD. Connecting to GV-IP Speed Dome Depending on where you save the created E-Map file (GV-System, E-Map Server or Control Center), the steps to open the Remote E-Map window for monitoring may vary slightly. The following is the connection example when you store the E-Map file in the GV-System.

  • Page 147: Chapter 9 Cms Configurations

    Chapter 9 CMS Configurations This section introduces the related settings to enable connecting to the GV-IP Speed Dome in the central monitoring stations Center V2 and VSM and Dispatch Server. 9.1 Center V2 The Center V2 can monitor the video and I/O devices connected from the GV-IP Speed Dome.
  • Page 148 To define how to display the received video on motion detection and input trigger from the GV-IP Speed Dome, click the Preference Settings button and select System Configure. This dialog box appears. Figure 9-3 Manual close channel: Closes the triggered camera view manually. Close the camera view when motion stopped: Closes the triggered camera view automatically when motion stops.

  • Page 149: Vsm

    CMS Configurations 9.2 VSM The VSM can monitor the video and I/O devices connected from the GV-IP Speed Dome. TCP/ IP GV-IP Speed Dome Text Data GV-IP Speed Dome Figure 9-4 To set the appropriate port connecting to the GV-IP Speed Dome, click Configure on the window menu, and select System Configure to display this dialog box.

  • Page 150: Dispatch Server

    9.3 Dispatch Server The Dispatch Server can manage the video and I/O devices connected from the GV-IP Speed Dome, and distribute them to the Center V2. TCP/ IP GV-IP Speed Dome Center V2 Video Data Text Data Dispatch Server GV-IP Speed Dome Center V2 Figure 9-6 To enable connecting to the GV-IP Speed Dome, click the Server Setting button on...

  • Page 151: Chapter 10 Smart Device Connection

    Smart Device Connection Chapter 10 Smart Device Connection Using Android or Apple smart devices, you can receive live video streaming from the GV-IP Speed Dome. The charts below list the GV mobile applications supporting the GV-IP Speed Dome. Smart Device View OS Supported Default Port Android V2.2 to 4.0.4...

  • Page 152: Android

    10.1 Android Download GV-Eye from Android Market and install the application. The GV-Eye icon will appear on the desktop. Figure 10-1 10.1.1 Connecting to GV-IP Speed Dome 1. Tap the GV-Eye icon on you device, and then this page appears. Figure 10-2 2.
  • Page 153 Smart Device Connection Figure 10-3 4. Tap the Connection button to access the GV-IP devices.

  • Page 154: Accessing Live View

    10.1.2 Accessing Live View You can press the Menu button on the mobile phone to see or hide the connection information. Motion Detected I/O Triggered Motion Detected Figure 10-4 The following function buttons are available: Icon Name Function Channel Switches to a different channel. You can drag across number the numbers to see more channels.
  • Page 155 Smart Device Connection Icon Name Function Audio Enables or disables the audio function. G.711 and G.723 audio codec are supported. PTZ Control Enables the PTZ function. A message will appear asking if you want to use Gesture Detector to control PTZ.

  • Page 156: Apple

    10.2 Apple Download GV-Eye / HD from App Store and install the application. The GV-Eye / GV-EyeHD icon will appear on the desktop. GV-Eye icon on iPnone / iPod Touch GV-Eye HD icon on iPad Figure 10-5...

  • Page 157: Connecting To Gv-Ip Speed Dome

    Smart Device Connection 10.2.1 Connecting to GV-IP Speed Dome To connect your iPhone, iPod Touch or iPad to the GV-IP Speed Dome, follow these steps: 1. Click the GV-Eye icon on the desktop of your phone. The welcome page appears. 2.

  • Page 158: Accessing Live View

    10.2.2 Accessing Live View You can tap the information button at the top-right corner to see the connection information. Figure 10-8 The buttons below are available when the iPhone, iPod Touch or iPad is positioned vertically. Icon Name Function Screen division Displays up to four channels on the same page if the GV-IP device supports multiple channels.
  • Page 159 Smart Device Connection Note: The PTZ control and I/O device functions are only accessible on devices with PTZ control and I/O devices. The default live view is stream 2, limited to Admin users only in GV-Eye (HD) V1.2.0.

  • Page 160: Gv-Ip Speed Dome Specifications

    GV-IP Speed Dome Specifications Camera Image Sensor 1/2.8’’ CMOS Optical Zoom Digital Zoom Effective Pixels Horizontal Resolution Scanning System Digital Interface Synchronization Internet Video Output > 50 dB (AGC Off) S/N Ratio 0.5 Lux (1/30 sec), high sensitivity Minimum Illumination 1.7 Lux (1/30 sec), typical Focal Length 4.7 ~ 94.0 mm...
  • Page 161 Appendix Mechanical Temperature Detector Power DC Jack Micro SD / SDHC / SDXC memory card slot (for Class 6 or Connectors Local Storage above) I/O wires Digital I/O Web Interface Installation & Management Web-based configuration Remote upgrade through Web Browser Firmware Upgrade IP Device Utility included in the Software CD live view, video recording, PTZ control, Preset, Sequence,...
  • Page 162 Temperature Outdoor -40°C ~ 50°C; -40°F ~ 122°F Humidity 20% ~ 90% (non-condensing) Waterproof Standard IP66 standard (GV-SD220-S only) Ø177 x 221.9 mm / 7 x 8.8 in Indoor Dimensions Outdoor Ø220 x 297.75 mm / 8.7 x 11.7 in Indoor 3.2 Kg / 7.1 lb...
  • Page 163 Appendix Applications Network Storage GV-NVR, GV-System, GV-Recording Server - GV-Eye for Android smartphone, tablet, iPhone and iPod Smart Device Access Touch - GV-Eye HD for iPad Live Viewing IE, Mobile Phone GV-Control Center, GV-Center V2, GV-VSM, GV-GIS CMS Server support All specifications are subject to change without notice.

  • Page 164: Appendix

    Appendix A. The CGI Command With GV-IP Speed Dome, you can obtain a snapshot of the live view or access the User Account Web interface simply by executing CGI commands. For a GV-IP Speed Dome with the following details: IP address: 192.168.2.11 Username: admin Password: admin Desired Stream: 1...

  • Page 165: Rtsp Protocol Support

    Appendix B. RTSP Protocol Support The GV-IP Speed Dome supports RTSP protocol for both video and audio streaming. For RTSP command, enter: rtsp://<IP of the GV-IP Speed Dome:8554/<CH No.>.sdp For example, rtsp://192.168.3.111:8554/CH001.sdp Note: The RTSP streaming provides source video images of 352 x 240 / 352 x 288 only. The RTSP server must be enabled on the Web interface.

  • Page 166: Settings For Internet Explorer 8

    C. Settings for Internet Explorer 8 If you use Internet Explorer 8, it is required to complete the following setting. 1. Set the Security to Medium-high (default). 2. Enable Allow previously unused ActiveX controls to run without prompt. 3. Disable Only allow approved domains to use ActiveX without prompt.

Table of Contents
