2.4 Connecting the Cables
With the Data Cable, you can connect the pow
I/O devices to the GV-IP Spee
below.
No.
Wire
1
Orange
2
Yellow
3
Green
4
Blue
5
Pink
6
Purple
7
White
8
Gray
10
er, microphone, speaker, and
d Dome. The Data Cable is illustrated as
I/O Wires
Microphone
Speaker
Ethernet
Definition
Ala
rm In 1
Alarm In 2
Alarm In 3
Alarm In 4
Ground
Alarm Out
Alarm Out Open
Alarm Out Close
Power Adapter
