Drive Carrier Leds; Table 4-2 Drive Carrier Leds - Silicon Graphics InfiniteStorage 3104 User Manual

4: System Interface

Drive Carrier LEDs

26
The server chassis uses SATA drives. Each SATA drive carrier has two LEDs.
the functions of the two LEDs.
Table 4-2 Drive Carrier LEDs
LED Description
Green When illuminated, this green LED (on the front of the SATA drive carrier)
indicates drive activity. A connection to the SATA backplane enables this LED
to blink on and off when that particular drive is being accessed.
Red An illuminated red LED indicates a SATA drive failure. If one of the SATA
drives fails, you should be notified by your system management software.
Refer to "Installing and Removing Hard Disk Drives" on page 32
failed drives.
Table 4-2 describes
for instructions on replacing
