Drive Carrier LEDs
30
The server chassis uses SATA drives. Each SATA drive carrier has two LEDs.
the functions of the two LEDs.
Table 4-2
Disk Carrier LEDs
LED
Description
Blue
Each Serial ATA drive carrier has a blue LED. When illuminated, this blue LED
(on the front of the SATA drive carrier) indicates drive activity. A connection to
the SATA backplane enables this LED to blink on and off when that particular
drive is being accessed.
Red
An illuminated red LED indicates a SATA drive failure. If one of the SATA
drives fails, you should be notified by your system management software.
Refer to
"Installing and Removing Disk Drives" on page 38
drives.
Table 4-2
for instructions on replacing failed
007-6471-001
describes
