4: System Monitoring

Drive Carrier LEDs

28
The server chassis uses SATA drives. Each SATA drive carrier has two LEDs.
the functions of the two LEDs.
Table 4-2 Disk Carrier LEDs
LED Description
Blue Each Serial ATA drive carrier has a blue LED. When illuminated, this blue LED
(on the front of the SATA drive carrier) indicates drive activity. A connection
to the SATA backplane enables this LED to blink on and off when that
particular drive is being accessed.
Red An illuminated red LED indicates a SATA drive failure. If one of the SATA
drives fails, you should be notified by your system management software.
Refer to "Installing and Removing Disk Drives" on page 36
drives.
Table 4-2
for instructions on replacing failed
007-6363-001
describes
