Installing the Outer Rails

Installing the Server in a Rack

!
007-6307-001
Do the following to install the outer rails:
1. Measure the distance from the front rail to the rear rail of the rack.
2. Attach a short bracket to the front side of the right outer rail and a long bracket to the rear
side of the right outer rail.
3. Adjust both the short and long brackets to the proper distance so that the rail can fit snugly
into the rack.
4. Secure the short bracket to the front side of the outer rail with two screws and the long
bracket to the rear side of the outer rail with three screws.
5. Repeat steps 2-4 for the left outer rail.
Warning:
Fully loaded, the ISS3104 server weighs about 43 lbs (19.5 kg). Always use
proper lifting techniques when your move the server. Always get the assistance of another
qualified person when you install the sever in a location above your shoulders. Failure to do
so may result in serious personal injury or damage to the equipment.
You should now have rails attached to both the chassis and the rack unit. The next step is to install
the server into the rack. Do the following as shown in
1. Align the rear of the chassis rails with the front of the rack rails.
2. Keeping the pressure even on both sides, slide the chassis rails into the rack rails.
You may need to depress the locking tabs when inserting. When the server has been pushed
completely into the rack, you should hear the locking tabs click.
Installing the System into a Rack
Figure 3-3:
