3.7.3 Data Writing Procedures

a. Connect a signal cable to INPUT2 of the unit in which the data are being written.
b. Set the data writing unit in the factory mode. (Refer to 2.2.3 Service mode/ factory mode)
c. Copy all the files of the sRGB data writing software in a floppy diskette.
d. Insert this floppy diskette and start the personal computer. Then, the following screen is displayed:
SRGB data writing Soft ware
f1
G.sRGB G.TEXT G.VIDEO sRGB C VIDEO C W/B Col SEL MENU Key lock Model
e. Operation key allotment
F1: sRGB-GAMMA writing ON/OFF
F2: TEXT-GAMMA writing ON/OFF
F3: VIDEO-GAMMA writing ON/OFF
F4: sRGB-Color writing ON/OFF
F5: VIDEO-Color writing ON/OFF
F6: White-Balance writing ON/OFF
F7: 5000K to 9600K, NATIVE change
F8: Monitor data, EEPROM Data ALL SAVE, EEPROM Data ALL Write, EEPROM Data EDIT
F9: F1 to F6 key operation lock
F10: Model selection
ESC: Return or End
Enter key: Fixed value writing for brightness (hue data), color temperature (white balance), and γ data
(sRGB, TEXT, VIDEO)
In these procedures, only the Enter key is to be operated.
LCD2080UX: LCD2080UX sRGB DATA
SRGB FILE: sRGB_03.TXT(2003/02/13 17:53)
**************************************************
*
* Data is written in.
*
* Please push Enter key
*
**************************************************
f2 f3 f4 f5
*
*
*
*
*
f6 f7 f8 f9
4-8
