Specifications
Monitor Specifications
LCD Module
Viewable Image Size: 51 cm/20.1 inches
Native Resolution (Pixel Count): 1600 x 1200
Input Signal
Display Colours
Synchronization Range Horizontal: 31.5 kHz to 91.1 kHz
Viewing Angle Left/Right: ±88° (CR > 10)
Image Formation Time
Resolutions Supported Landscape: 720 x 400*
Active Landscape: Horiz.: 408 mm/16.1 inches
Display Area
Portrait: Horiz.: 306 mm/12.0 inches
Power Supply
Current Rating
Dimensions Landscape: 442 mm (W) x 366.3 ~ 496.3 mm (H) x 200 mm (D)
Height Adjustment: 130 mm/5.1 inches (Landscape)
Weight
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Storage Temperature: -10°C to 60°C/14°F to 140°F
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
MultiSync LCD2080UX Monitor
Diagonal: 51 cm/20.1 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7V p-p and Sync Negative 0.3V p-p)
16,777,216
Vertical: 50 Hz to 85 Hz
Up/Down: ±88° (CR > 10)
25 ms (Typ.)
1 : VGA-Text
640 x 480* 1 at 60 Hz to 85 Hz
1
800 x 600* at 56 Hz to 85 Hz
832 x 624* 1 at 75 Hz
1024 x 768* 1 at 60 Hz to 85 Hz
1
1152 x 870* at 75 Hz
1280 x 1024* 1 at 60 Hz to 85 Hz
1600 x 1200 at 60 Hz....................... performance.
1
Portrait: 480 x 640* at 60 Hz to 85 Hz
600 x 800* 1 at 56 Hz to 85 Hz
624 x 832* 1 at 75 Hz
1
768 x 1024* at 60 Hz to 85 Hz
870 x 1152* 1 at 75 Hz
1024 x 1280* 1 at 60 Hz to 85 Hz
1200 x 1600 at 60 Hz....................... performance.
Vert.: 306 mm/12.0 inches
Vert.: 408 mm/16.1 inches
AC 100-240 V ~ 50/60 Hz
0.7 - 0.35 A
17.4 inches (W) x 14.4 ~ 19.5 inches (H) x 7.9 inches (D)
Portrait: 340 mm (W) x 458.3 ~ 547.3 mm (H) x 200 mm (D)
13.4 inches (W) x 18.0 ~ 21.5 inches (H) x 7.9 inches (D)
10.5 kg (23.1 lbs)
Humidity: 30% to 80%
Feet: 0 to 12,000 Feet
Humidity: 10% to 85%
Feet: 0 to 40,000 Feet
Notes
Active matrix; thin film transistor (TFT) liquid
crystal display (LCD); 0.255 mm dot pitch;
250 cd/m
typical.
Digital Input: DVI
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
NEC-Mitsubishi Electronics Display cites
recommended resolution for optimal display
Some systems may not support
all modes listed.
NEC-Mitsubishi Electronics Display cites
recommended resolution for optimal display
English-12
1-40
2
white luminence; 350:1 contrast ratio,
