Security Trigger Zones

If the security system has been triggered the LED will flash one of the patterns
below indicating the zone.
LED FLASHES
1 Flash
2 Flashes
3 Flashes
4 Flashes
5 Flashes

Remote Start Shutdown Diagnostics

If the remote start shuts down or fails to start, the parking lights and LED will flash
one of the patterns below indicating the shutdown input.
LED FLASHES
3 Flashes
4 Flashes
7 Flashes
2012 Audiovox Electronics Corporation. All rights reserved.
TRIGGER ZONE
Shock Sensor
Trunk Input
Door Input
Ignition Input
Hood Input
TRIGGER ZONE
Hood Input
Brake Input
Manual Transmission Mode not ready
Remote Start Valet Mode
Tach not learned / Crank Average not learned
