12 PURPLE
Locate the vehicle's dome light or door pin switch wire.
Verification: This wire will register positive voltage (POS) when the door is
opened and the interior light is on. This wire will
register ground or "0" Volts when the door is closed and the interior light is
off.
Connect the PURPLE wire to the vehicle's positive door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide.
13 BROWN
Locate a suitable mounting location in the engine compartment for the siren, away
from moving parts.
With the bell of the siren aiming downwards, secure the siren in place using self
tapping screws, being careful not do drill into any hoses, wiring or components.
Connect the BLACK siren wire to a chassis ground using a ring terminal and self
tapping screw (not supplied).
Route the BROWN siren output wire from the control module through the firewall
and connect to the RED wire on the siren.
NOTE: Be sure to loom the siren wires, and seal the grommet.
14 GRAY/RED
Locate the vehicle's parking brake wire.
Verification: This wire will register ground when the vehicle is in PARK or
NEUTRAL or if the PARKING BRAKE is engaged.
NOTE: The following connection is required for Turbo Timer and Manual
Transmission Mode.
2012 Audiovox Electronics Corporation. All rights reserved.
DOOR TRIGGER INPUT ( + )
SIREN OUTPUT ( + )
PARKING BRAKE INPUT ( - )
