Security Trigger Zones

If the security system has been triggered the LED will flash one of the patterns below
indicating the zone.
LED FLASHES
2 Flashes
3 Flashes
4 Flashes
5 Flashes

Remote Start Shutdown Diagnostics

If the remote start shuts down or fails to start, the parking lights will flash one of the
patterns below indicating the shutdown input.
To manually enter diagnostics and view the last shutdown, turn the ignition ON and
press and release the
LED FLASHES
3 Flashes
4 Flashes
5 Flashes
7 Flashes
2014 Voxx Electronics Corporation. All rights reserved.
TRIGGER ZONE
Hood / Trunk Input
Door Input
Shock Sensor
Ignition Input
button.
SHUTDOWN ZONE
Hood Input
Brake Input
Neutral Safety Input
Remote Start Valet Mode
Manual Transmission Mode not set (manual
transmission models only)
Tach not learned / Crank Average not learned
