Code Alarm professional series PROCOMP Installation Manual page 14

2 Pin Transponder Bypass Harness
1 RED
Provides a constant 500mA +12V output intended for use with the transponder
output wire for activating a transponder bypass interface during remote start.
2 BLACK
The transponder output wire provides a ( - ) 500mA output when the remote start
function is activated and remains until 4 seconds after the remote start is
shutdown.
Programmable output: While RS is ON, During Start, Until IGN OFF.
6 Pin Start Harness
1 RED
Locate the vehicle's constant battery wire(s) at the ignition switch.
Verification: These wires will register ( + ) voltage in all positions of
the ignition switch.
Connect the RED wire to the vehicle's battery wire.
NOTE: Remove all fuses until all connections are made.
If the vehicle is equipped with more than one battery wire at the ignition switch,
connect the RED wire from the 4 pin harness and the RED wire from the 6 pin
2 ORANGE
Locate the vehicle's accessory wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to ACC
(Accessory) and the ON (or RUN) position. The voltage drops out when the
key is turned to the START (or CRANK) position.
Connect the ORANGE wire to the vehicle's accessory wire.
14
IMPORTANT!
harness to separate vehicle battery wires.
BATTERY 12V ( + )
TRANSPONDER OUTPUT ( - )
BATTERY 12V ( + )
ACCESSORY 1 ( + )
