Pin Transponder Bypass Harness; Pin Start Harness; Pin Alternate Output Harness - Code Alarm professional series PROCOMP Installation Manual

2 Pin Transponder Bypass Harness

1
2

6 Pin Start Harness

1
2
3
4
5
6

4 Pin Alternate Output Harness

1
2
3
4
4 Pin Auxiliary Output Harness
1
2
3
4
3 Pin Lock Output Harness
1
2
3
6
RED
BLACK
RED
ORANGE
ORANGE/WHITE
PINK/WHITE
BROWN/RED
BLUE/BLACK
BLACK/YELLOW
GREEN/WHITE
LT BLUE
LT GREEN/BLACK
ORANGE/BLACK
GRAY/BLACK
WHITE/BLACK
VIOLET/BLACK
BLUE/GREEN
BLUE
GREEN
BATTERY 12V ( + )
TRANSPONDER OUTPUT ( - )
BATTERY 12V ( + )
ACCESSORY 1 ( + )
ACCESSORY 2 ( + )
IGNITION 2 ( + )
BRAKE INPUT ( + )
START STATUS / ACTIVE OUTPUT ( - )
PULSE DURING CRANK ( - )
PULSE AFTER SHUTDOWN ( - )
FACTORY ARM / PULSE AFTER START ( - )
FACTORY DISARM / PULSE BEFORE START ( - )
AUX 4 OUTPUT ( - )
AUX 3 OUTPUT ( - )
AUX 2 OUTPUT ( - )
AUX 1 OUTPUT ( - )
2ND UNLOCK ( - )
NEG UNLOCK / POS LOCK
NEG LOCK / POS UNLOCK
