Code Alarm professional series PROCOMP Installation Manual page 13

22 ORANGE
This wire will have a continuous ( - ) 500mA output when the system is Armed. This
wire is typically used for controlling window modules or additional sensors.
4 Pin Power Harness
1 RED
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
2 GREEN
3 PURPLE
Locate the vehicle starter wire.
Verification: This wire registers voltage only when the key is turned to the
START position. Cut the vehicle's starter wire in half.
Verification after starter wire is cut:
KEY SIDE of starter wire registers voltage when the key is turned to the
START position.
MOTOR SIDE of starter wire registers no voltage.
Connect the GREEN wire to the KEY SIDE of the vehicle starter wire at the ignition
switch harness.
Connect the PURPLE wire to the MOTOR SIDE of the vehicle starter wire.
4 PINK
Locate the vehicle's ignition wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position. The voltage does not drop out when the key is turned to the
START (or CRANK) position.
Connect the PINK wire to the vehicle's Ignition wire.
This wire is also used for Ignition 1 Output.
2012 Audiovox Electronics Corporation. All rights reserved.
ARMED OUTPUT ( - )
BATTERY 12V ( + )
STARTER INPUT - KEY SIDE
STARTER OUTPUT - MOTOR SIDE
IGNITION 1 INPUT/OUTPUT ( + )
13
