Code Alarm professional series PROCOMP Installation Manual page 18

2 GRAY/BLACK
This wire provides a ( - ) 500mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
To activate refer to the transmitter button configuration chart. Please refer to the
selectable options for timing.
Selectable timing: Push & Hold, 10 Seconds, 20 Seconds, Latched ON until
ignition ON, Latched ON until button press.
3 WHITE/BLACK
This wire provides a ( - ) 500mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
To activate refer to the transmitter button configuration chart. Please refer to the
selectable options for timing.
Selectable timing: Push & Hold, 10 Seconds, 20 Seconds, Latched ON until
ignition ON, Latched ON until button press.
4 VIOLET/BLACK
This wire provides a ( - ) 500mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
To activate refer to the transmitter button configuration chart. Please refer to the
selectable options for timing.
Selectable timing: Push & Hold, 10 Seconds, 20 Seconds, Latched ON until
ignition ON, Latched ON until button press.
18
AUX 3 OUTPUT ( - )
AUX 2 OUTPUT ( - )
AUX 1 OUTPUT ( - )
2012 Audiovox Electronics Corporation. All rights reserved.
